Adapted diaMeter 16mm formed Metering Rod, the total length of 2000mm, through the special structure to correct the straightness of the Rod body, to ensure stable rotation and full contact with the substrate, improve the thickness control accuracy of Spreader.
Wet film thickness 22.9 microns, diaMeter 9.52 mm, the forming Rod uses an extrusion process to process continuous grooves, with no wire breakage and easy cleaning; the wire-wound Rod is based on the traditional principle, and there are differences in coating amount.
Wet film thickness 45μm, main Rod diaMeter 10mm, effective application width 600mm, using SUS304 material, Coating Weight, length and surface preparation can be customized, suitable for a variety of Spreader conditions.
Using the formed pRoduction process, Coating Weight is about twice that of the wire-wound coating Rod, wet film thickness is 13μm, film accuracy reaches 0.5 μm, and the material is 304 stainless steel.
Equipped with 1 tie Rod and 10 adapters, the specifications cover M6 to M24, and are suitable for a variety of bolt sizes to ensure test compatibility and ease of operation.
With bar and Drawdown blade two Spreader mode, using clamshell Drawdown blade head and new bar Installation method, easy to clean. Spreader speed and length can be freely adjusted, film thickness control accuracy is high, suitable for Glass, cardboard and other substrates.
The formed process ensures that the film is uniform, the film thickness is 118.9μm, the Rod diaMeter is 9.5mm, the total length is 40cm, and the effective application width is 30cm.
The photoelectric counter is used to realize automatic counting, and the measurement is fast and accurate; the period of M-3 swing Rod is 0.625s, and the swing time on standard Glass is 440 +/- 6s; the horizontal mechanism is improved, and the scale can be moved horizontally to facilitate zero adjustment.
Adopt double guide Rod structure to improve Stability, Maximum load 1000N, Support stepless speed regulation and four test modes, Have force holding and tension breaking stop function.
Using wire-wound stainless steel main Rod structure, wet film thickness 91.4 μ m, application width 300mm, through the formed process to achieve accurate Spreader, easy to operate.
Spreader speed 5-180mm/s adjustable, wire Rod Spreader accuracy +/- 0.001mm, using touch screen control and mechanical fixture to ensure stable and reliable Spreader process.
The wet film thickness is 22.9 microns, the application width is 300mm, the stainless steel material is used, the forming Rod is processed by extrusion process, the continuous wire is easy to clean, and the wire-wound drawdown bar is widely used based on traditional principles.
Stability is ensured by double guide Rod structure, with a maximum load of 500N, four test modes and force holding functions are supported, and a stop-and-break and limit protection device is provided.
Drawdown blade and bar coating method, with Vacuum chuck function, high film thickness control accuracy, application length and speed can be adjusted freely, easy to clean, suitable for a variety of substrates.
Wire-wound structure ensures 0.1 micron High Accuracy, wet film thickness 50.3 μm, stainless steel material is durable and easy to clean, and the wide-Rod Film Applicator achieves uniform coating.
