Overview
CNSHP DC1006 Digital Display Low Temperature Circulating Bath adopts single-chip microprocessing control, self-tuning PID adjustment, imported High Accuracy Platinum Resistance (Pt100) temperature measurement, high temperature control accuracy and low Fluctuation. The Compressor with good fully enclosed technology has high cooling efficiency, low noise, stable and reliable instrument operation, convenient and safe operation. Suitable for internal/external temperature control applications, the sample can be placed directly in the open bath thermostatic, or it can be externally controlled Measurement unit that requires thermostatic.
Features
1. Adopt microcomputer temperature control PID adjustment, self-tuning control technology, temperature control accuracy up to +/- 0.05 ℃
2. Fully enclosed brand Compressor refrigeration system, no CFC, fast cooling
3. Temperature range optional -50~ 100 ℃, capacity range optional 6L, 10L, 15L, 20L, 30L, support customization
4. The fuselage shell adopts anti-aging electrostatic spraying technology, and the platen liner mixing pump is made of good SUS304 stainless steel material, which is excellent in workmanship
5. Humanized R rounded corner design structure can avoid operators being injured by edges and corners
6. Removable ventilation grille, easy to clean refrigeration unit condenser
7. The domestic circulation function adopts a non-heat centrifugal circulation pump to avoid the traditional water pump from affecting the temperature field of the tank due to its own heat production
8. The external circulation function can be circulated through the external circulation of thermostatic liquid to establish a second temperature field
9. Multiple Safety protection devices: power-off protection, upper and lower limit temperature setting, temperature loss protection and alarm, low water level anti-dry burning and explosion-proof heating device, Compressor overheating and overcurrent protection, Sensor open circuit display
Principle
The Low Temperature Circulating Bath is controlled by a single-chip microprocessing self-tuning PID adjustment, combined with imported High Accuracy Platinum Resistance (Pt100) temperature measurement, to achieve accurate temperature control. The fully enclosed Compressor refrigeration system or dual Compressor cascade refrigeration technology (below -40 ° C or 30 liters series), combined with professional circulating stirring design, ensures that the liquid in the tank forms a uniform and smooth dispersion and smooth heat exchange in the internal circulation.
Applications
Bioengineering, food, chemical industry, metallurgy, chemical analysis, petroleum, research institutes, universities, factory laboratories, Quality control department, thermostatic field: Sensor detection, thermostatic biochemical reaction, thermostatic material aging, etc. Biochemical field: Rotary evaporator, Abbe refractometer, Viscometer, Rheometer, Polarimeter, atomic absorption, ICP-MS, ICP, nuclear magnetic resonance, CCD, biological fermentation tank, chemical reactor (synthesizer), etc. Material field: electron microscopy, X-Rays diffraction, X-fluorescence, vacuum sputtering Eletroplating, vacuum coating machine, ICP etching, various semiconductor equipment, fatigue testing machine, chemical deposition system, atomic deposition system Physical and chemical fields: lasers, magnetic fields, various molecular pumps, diffusion pumps, ion pumps, and materials
Steps
1. Place the instrument in a stable position and connect it to the power supply
2. Choose domestic circulation or external circulation mode as needed
3. Set the target temperature and start the device for thermostatic control
4. Monitor temperature fluctuations to ensure stable operation
5. Turn off the device and disconnect the power after use
Notice
• Power supply voltage meets 220VAC +/- 10%, 50Hz requirements
• Check the water level before use to avoid dry burning of the heating device
• Regularly clean ventilation grilles and condensers
• Be careful to avoid contact with high or low temperature surfaces during operation
• Safety protection settings to prevent temperature runaway
• Temperature range using the appropriate medium (e.g. pure water, ethylene glycol, alcohol)
