Overview
CNSHP DC2010 digital display Low Temperature Circulating Bath adopts single-chip microprocessing control, self-tuning PID adjustment, imported High Accuracy Platinum Resistance (Pt100) temperature measurement, high temperature control accuracy and low Fluctuation. The Compressor with fully enclosed technology has high cooling efficiency, low noise, stable and reliable instrument operation, convenient and safe operation. Suitable for internal and external temperature control applications, the sample can be placed directly in the open bath thermostatic, or an external measurement unit that requires thermostatic can be externally controlled.
Features
1. Adopt microcomputer temperature control PID adjustment, self-tuning control technology, temperature control accuracy up to +/- 0.05 ℃
2. Fully enclosed brand Compressor refrigeration system, no CFC, fast cooling
3. Temperature range -50~ 100 ℃, capacity range 6L, 10L, 15L, 20L, 30L, can be customized
4. The fuselage shell adopts anti-aging electrostatic spraying technology, and the platen liner mixing pump is made of SUS304 stainless steel
5. Humanized R rounded corner design structure to avoid operators being injured by edges and corners
6. Removable ventilation grille, easy to clean refrigeration unit condenser
7. The domestic circulation function adopts a non-heat centrifugal circulation pump to avoid the traditional pump's own heat generation affecting the temperature field of the tank
8. The external circulation function can be circulated through the external circulation of thermostatic liquid to establish a second temperature field
9. Multiple Safety protection devices: Power off protection, upper and lower limit temperature setting, temperature loss protection and alarm, low water level anti-dry burning and explosion-proof, Compressor overheating and overcurrent protection, Sensor open circuit display function
Principle
The Low Temperature Circulating Bath adopts self-tuning PID adjustment technology through a microcomputer temperature control system, combined with imported High Accuracy platinum resistance (Pt100) temperature measurement, to achieve accurate temperature control. The fully enclosed Compressor refrigeration system is used for cooling, and the liquid in the tank is uniform and smooth through professional circulation stirring design, and the heat exchange is smooth. Suitable for internal and external circulation temperature control, providing a constant temperature field source.
Applications
Bioengineering, Food, Chemical Industry, Metallurgy, Chemical Analysis, Petroleum, Thermostatic Fields: Sensor Detection, Thermostatic Biochemical Reaction, Thermostatic Material Aging, etc. Biochemical Fields: Rotary evaporator, Abbe refractometer, Viscometer, Rheometer, Polarimeter, Atomic Absorption, ICP-MS, ICP, Nuclear Magnetic Resonance, CCD, Biological fermentation tank, Chemical Reactor (Synthesizer), etc. Material Fields: Electron Microscopy, X-Rays Diffraction, X-Fluorescence, Vacuum Sputtering Eletroplating, Vacuum Coating Machine, ICP Etching, Various Semiconductor Equipment, Fatigue Testing Machine, Chemical Deposition System, Atomic Deposition System, etc. Physicochemical Fields: Lasers, Magnetic Fiel Pumps, ion pumps, and materials
Steps
1. Place sample in open bath or external Measurement unit
2. Set the required temperature parameters
3. Start domestic circulation or external circulation function
4. Monitor temperature fluctuations and operating conditions
5. Clean the equipment and turn off the power after use
Notice
• Temperature range according to select the appropriate medium (such as pure water, ethylene glycol, alcohol, etc.)
• Power supply voltage 220VAC +/- 10%, 50Hz
• Regularly clean the removable ventilation grille to maintain cooling efficiency
• Pay attention to the low water level protection function to prevent the heating device from dry burning
• Avoid disassembling or modifying equipment without authorization
• Safety protection device is checked before use
