Overview
CNSHP DC6515 Digital Display Low Temperature Circulating Bath adopts single-chip microprocessing control, self-tuning PID adjustment and imported High Accuracy Platinum resistance temperature measurement, with high temperature control accuracy and small Fluctuation. With fully enclosed Compressor or imported double Compressor cascade refrigeration technology, the refrigeration efficiency is high, the noise is low, and the work is stable and reliable. The user-friendly design includes folding handle, heavy duty with self-locking casters, integral foaming process heat insulation, and professional circulating mixing design to ensure uniform and smooth liquid in the tank. Suitable for internal/external temperature control applications, can be directly in the tank thermostatic or external control of external equipment.
Features
1. Adopt microcomputer temperature control PID adjustment, self-tuning control technology, temperature control accuracy up to +/- 0.05 ℃
2. Fully enclosed brand Compressor refrigeration system, no CFC, fast cooling
3. Temperature range -50~ 100 ℃, medium according to the temperature of pure water, ethylene glycol, alcohol, etc., support customization
4. Capacity range optional 6L, 10L, 15L, 20L, 30L, support customization
5. The fuselage shell is anti-aging static spray, and the liner and mixing pump are made of SUS304 stainless steel, which is well-made
6. Fine chassis front panel and countertop, user-friendly R rounded corner design to avoid operator injury
7. Removable ventilation grille, easy to clean refrigeration unit condenser
8. The domestic circulation function adopts a non-heat centrifugal circulation pump to avoid its own heat generation affecting the temperature field
9. The external circulation function can circulate the thermostatic liquid externally to establish a second temperature field
10. Safety protection device includes power-off protection, upper and lower limit temperature setting, temperature loss protection and alarm, low water level anti-dry burning and explosion-proof, Compressor overheating and overcurrent multiple protection, Sensor open circuit display function
Principle
The Low Temperature Circulating Bath performs self-tuning PID adjustment through a microcomputer temperature control system, and uses imported High Accuracy platinum resistance temperature measurement to achieve accurate temperature control. The fully enclosed Compressor or double Compressor cascade refrigeration technology, combined with professional circulation mixing design, ensures that the liquid in the tank forms a uniform and smooth dispersion in the internal circulation, and the heat exchange is smooth. The domestic circulation adopts a heat-free centrifugal circulation pump to avoid the traditional water pump heat generation affecting the temperature field; the external circulation function allows the liquid to be introduced externally to establish a second temperature field.
Applications
Bioengineering, food, chemical industry, metallurgy, chemical analysis, petroleum, thermostatic field, biochemical field, materials field, physicochemical field
