Overview
CNSHP DC-0520T Low Temperature Perspective Thermostatic water bath is a low temperature thermostatic equipment using microcomputer temperature control and self-tuning PID adjustment technology, with high temperature control accuracy and small Fluctuation. The instrument adopts a fully enclosed brand Compressor refrigeration system, which has high refrigeration efficiency, low noise, stable and reliable work, convenient and safe operation. Equipped with professional circulating stirring design to ensure uniform temperature in the tank, suitable for internal and external temperature control applications.
Features
1. Adopt microcomputer temperature control PID adjustment, self-tuning control technology, temperature control accuracy up to +/- 0.05 ℃
2. Fully enclosed brand Compressor refrigeration system, no CFC, fast cooling
3. Temperature range -50~ 100 ℃, capacity range 6L to 30L, support customization
4. The fuselage shell is anti-aging static spray, and the liner and mixing pump are made of SUS304 stainless steel
5. Humanized R rounded corner design to avoid operator injuries
6. Removable ventilation grille for easy cleaning
7. The domestic circulation adopts a non-heat centrifugal circulation pump to avoid its own heat generation affecting the temperature field
8. The external circulation function can establish a second temperature field
9. Multiple Safety protection devices: Power-off protection, upper and lower limit temperature setting, temperature loss alarm, low water level anti-dry burning, Compressor overheating and overcurrent protection, Sensor open circuit display
Principle
The equipment realizes self-tuning PID adjustment through single-chip microprocessing control, and adopts imported High Accuracy Platinum Resistance (Pt100) temperature measurement to ensure accurate temperature control. The refrigeration system adopts a fully enclosed Compressor (below -40 ° C or 30 liters series adopts imported double Compressor cascade refrigeration technology), combined with professional circulation stirring design, so that the liquid in the tank forms a uniform and smooth domestic circulation and realizes smooth heat exchange.
Applications
Bioengineering, food, chemical industry, metallurgy, chemical analysis, petroleum, thermostatic field, biochemical field, materials field, physicochemical field
Steps
1. Place the device in a stable position and connect it to the power supply
2. Select the appropriate medium (pure water, ethylene glycol, alcohol, etc.) according to the Temperature range and add the Tank
3. Turn on the power supply and set the required temperature parameters
4. Start domestic circulation or external circulation function
5. Monitor the temperature display to ensure stability at the set value
6. After use, turn off the power and clean the equipment
Notice
• Power supply voltage meets 220V +/- 10%, 50Hz requirements before use
• Choose the medium correctly according to the Temperature range to avoid the use of improper liquids
• Regularly clean ventilation grilles and condensers to maintain cooling efficiency
• Pay attention to low water level protection to prevent the heating device from dry burning
• Avoid contact with high or low temperature surfaces during operation to prevent burns or frostbite
• Use handles or casters when moving your device, pay attention to safety
• Immediately stop use and check if there is a temperature runaway or alarm
• When not in use for a long time, the medium should be emptied and kept drying
