Overview
YIHENG BPMJ-250F mildew incubator is a new generation of incubator products. The company has more than ten years of experience in design and manufacturing, and adopts fluorine-free environmentally friendly design. The product has the functions of mold fostering and thermostatic oscillation fostering, and is equipped with an ultraviolet sterilization system, which can effectively prevent pollution during cell fostering. Based on the humanized design concept, starting from the actual needs of customers, we try our best to meet customer requirements in every detail.
Features
1. Humanized design: fluorine-free environmental protection design, large-screen LCD display, mirror stainless steel liner, left test hole, support thermostatic oscillation foster
2. Quality assurance: brand Compressor and circulating fan, fuzzy PID controller, with timing function
3. Automatic control of circulating fan speed: automatically adjust the wind speed according to the temperature state
4. Self-diagnosis function: LCD screen fault information prompt
5. LCD multi-segment programmable controller: 7 groups of 63 steps can be programmed, supporting Multi-Parameter settings such as temperature, wind speed, time, etc
6. Convenient data processing: optional printer, 485 Communication interface and USB data transfer interface
7. Safety function: independent temperature limit alarm system, automatic alarm for high temperature and overtemperature
8. UV sterilization system: regularly disinfect the inside of the box
Principle
Brand Compressor and circulating fan are used to ensure uniform temperature and Humidity in the working room through a unique air duct circulation system. Fuzzy PID controller realizes accurate temperature control, and the circulating fan speed can be automatically controlled according to the temperature state. When the temperature in the box is constant, the wind speed can be automatically reduced to avoid sample volatilization. Equipped with ultraviolet sterilization system, the air in the box can be disinfected regularly.
Applications
Mold foster, cell foster, thermostatic oscillation foster, laboratory foster
Standards
No relevant information
Steps
1. Turn on the power supply AC220V 50Hz
2. Set temperature, time and other parameters through the large-screen LCD display interface
3. Multi-stage program control can be set as required
4. Put in the sample and start fostering
5. Optional ultraviolet sterilization function for regular disinfection
6. Can be connected to a printer or computer for data recording through the optional interface
Notice
• Ambient Temperature should be in the range of + 5~ 35 ℃
• Note Temperature Fluctuations: High Temperature +/- 0.3 ℃, Low Temperature +/- 0.5 ℃
• Temperature Uniformity of +/- 1.5 ℃ (at 25 ℃)
• If the temperature exceeds the limit, the operation will be automatically interrupted and alarmed
• Regularly use an ultraviolet sterilization system for disinfection
• Relevant functional components can be selected according to needs
