Overview
RONGHUA INSTRUMENT 78-1 Magnetic Stirrer is easy to operate and adopts stepless speed regulation technology, which can precisely and stably stir liquid solutions in a wide speed range, especially suitable for small volume samples. The product belongs to the non-heating Magnetic Stirrer, which is a satisfactory tool for modern petroleum, chemical industry, environmental protection, biochemistry, experimental analysis, education and scientific research.
Features
1. Easy to operate, stepless speed regulation, can achieve precise and stable mixing in a wide speed range
2. Especially suitable for small sample testing
3. Max. stirring Capacity 1000mL, to meet a variety of experimental needs
4. The stirring speed range is 0~ 2400rpm, and the adjustment is flexible
5. Working plate size φ 125mm, strong adaptability
6. One-way mixing working mode, stable operation
Principle
The Magnetic Stirrer generates a swirl/spin magnetic field through the magnet in the base, which drives the stirrer placed in the container to synchronize the swirl/spin, so as to realize the stirring and mixing of the liquid. The stepless speed control system can precisely control the stirring speed to ensure the Stability and uniformity of the stirring process.
Applications
Petroleum, chemical industry, environmental protection, biochemistry, experimental analysis, education and research
Steps
1. Place the Stirrer on a smooth work surface
2. Turn on the power supply and turn on the power switch
3. Place the container containing the liquid on the work plate
Step 4 Put the appropriate stirrer in the container
5. Adjust the speed knob to the desired stirring speed
6. After use, first adjust the speed to the lowest level, and then turn off the power switch
STEP 7 Clean work plates and mixers
Notice
• Please ensure that the work surface is flat and stable before use
• The stirring speed should be gradually increased from low speed
• The bottom of the container should be in full contact with the working plate
• Do not operate the equipment in a dry or anhydrous state
• It should be cleaned and maintained in time after use
• Do not overload, Max. stirring Capacity does not exceed 1000mL
