Overview
The HJJ series Force Gauge fixture is a fixture produced by HBO for supporting the Force Gauge test bench test. When the Force Gauge is assembled on the test stand for tensile testing, the fixture needs to be used to assist the test, and different models are applicable to different ranges. The conventional HJJ series has fifteen different models (HJJ-01~ HJJ-15), which are suitable for different fields such as tape, leather, clothing, rubber, electrical components, paper, etc.
Features
1. Designed for Force Gauge Test Benches
2. Offer fifteen different model options
3. Measured value up to 500N
4. Suitable for multi-material testing
Principle
When the Force Gauge is assembled on the test stand for tensile test, the test sample is fixed through the fixture to assist in the completion of the tensile force, destructive force, insertion force and other mechanical properties test.
Applications
Tape, Leather, Clothing, Rubber, Electrical Components, Paper, Cable, Plastic film
Steps
1. Fit the Force Gauge to the Test Rack
2. Select the appropriate fixture model
3. Use a fixture to secure the tested sample
4. Conduct tensile, destructive or insertion force tests
Notice
• Different models of fixtures have different application ranges, please choose the appropriate model according to the test requirements
• Measured value is 500N, do not overload
• Make sure that the fixture is firmly fixed with the tested sample before testing
