Overview
SDPTOP DCY-2006 Low Temperature Circulating Bath is an upgraded product of DC series Low Temperature Circulating Bath, which adopts intelligent LCD display and microcomputer thermostatic Control system. The instrument is composed of temperature control part, temperature sensor Pt100 platinum resistance, circulating stirring part, heater, refrigeration part, stainless steel inner tank and shell. Temperature range is -20~ 95 ℃, Temperature Fluctuation +/- 0.05 ℃, Display resolution 0.1 ℃.
Features
1. Upgraded Products of DC Series Low Temperature Circulating Bath
2. Adopt newly designed LCD display and microcomputer thermostatic Control system
3. Can add communication function, two-way communication with computer
4. Liquid level alarm function
5.6 liters agitation pump capacity 8 L/min, Power 900W-2000W
6.15 liters agitation pump capacity 10 L/min, Power 1500W-3500W
7. Both the inner tank and the box are made of high-quality stainless steel
8. Temperature Fluctuation +/- 0.05 ℃, Display resolution 0.1 ℃
Principle
The instrument detects the temperature through the temperature sensor Pt100 platinum resistance, the microcomputer thermostatic Control system adjusts the heater and refrigeration department according to the difference between the set value and the Measured value, and the circulating stirring part ensures the uniform distribution of temperature. The intelligent LCD display monitors the temperature status in real time to achieve accurate temperature control.
Applications
Laboratory thermostatic control, scientific research, industrial testing
Steps
1. Turn on the power switch
2. Turn on the refrigeration switch and cycle switch as needed
3. Use the increase key, decrease key and shift key to set the temperature parameters
4. Confirm the setting through the function key
5. Monitor PV monitors and SV monitors to check temperature and settings
6. Observe the status of running indicators and alarm lights
Notice
• When the water level is low, the water replenishment indicator light is on, and it is necessary to replenish water in time
• The running indicator light is always on to indicate normal operation, and flashing to indicate self-tuning work
• The cooling light is on during the cooling output (not enabled)
• The heating light is on when the heating output is output
• When the alarm light is on, it indicates that the over-temperature alarm or water level indication is abnormal
• Check the liquid level before use to avoid low water level operation
