SDPTOP 501 Super Thermostatic Bath precision temperature control +/- 0.05 ℃

Name: SDPTOP 501 Super Thermostatic Bath precision temperature control +/- 0.05 ℃
Brand: SDPTOP
SKU: NB013924
Price: 394.0 USD
Availability: InStock

$ 394.00Ex works

Temperature Fluctuation +/- 0.05 ℃, Display resolution 0.1 ℃, Pump Flow rate 8L/min, with off-couple protection and over-temperature alarm function, internal/external circulation mode, Tank volume 20L.

Model

Get Quote

Category : Thermostatic Bath

Brand : SDPTOP

SKU : NB013924

Service :The delivery and service By NBCLab.Com

Overview

SDPTOP 501 Super Thermostatic bath is a precision temperature control equipment, using microcomputer Control system and imported Pt100 temperature sensor, providing 50~ 200 ℃ Temperature range, Temperature Fluctuation +/- 0.05 ℃, suitable for laboratory and industrial thermostatic needs.

Features

1. New design microcomputer precision thermostatic Control system; imported Pt100 temperature sensor 2. With breaking protection and over-temperature alarm function 3. Temperature Fluctuation +/- 0.05 ℃ 4. Display resolution 0.1 ℃ 5. Flow rate 8L/min 6. There is a condenser pipe, which can extend the lower limit temperature 7. The inner tank and box are made of high-quality stainless steel 8. With LCD display, with water level alarm function 9. With programmable function

Principle

The equipment precisely adjusts the temperature through the microcomputer Control system, uses the Pt100 temperature sensor to monitor the temperature in real time, and combines the internal/external circulation system to achieve a stable thermostatic environment.

Applications

Laboratory, industrial field

Temperature Range
50~95℃
Temperature Fluctuation
±0.05℃
resolution
0.1℃
opening dimensions
Ф150mm
groove depth
300mm
Pump circulation method
Inner and outer grooves
Total Power
1500W
Dimension
Ф300*490mm
Flow rate of pump
8L/min
Tank Volume
20L
Tank material
CH1015B stainless steel
Box material
CH1015B stainless steel
temperature sensor
Platinum Resistor Pt100
