Overview
The ECscan30 Pen Conductivity Meter is a BANTE brand Multi-Parameter pen conductivity /TDS meter with TDS measurement function, support for 3 point button calibrate and customizable TDS conversion factor. The meter is suitable for the measurement of liquid conductivity and total dissolved solids (TDS) values. Measurement accuracy is 1% F.S.
Features
1. Multi-Parameter Pen Conductivity Meter, including TDS measurement function.
2. Platinum Sensor, providing fast and stable measurement results.
3. Adjustable TDS conversion factor to meet different water quality testing requirements.
4.1 to 3 point button calibrated to automatically identify Conductivity detector standard solution.
5. Automatic temperature compensation, providing accurate Measured value in the full range.
6. Automatic end point locking, maintaining stable readings for easy browsing or recording.
7. Low battery alarm icon, prompting battery residual power.
8. Automatic power off, effectively saving battery energy consumption.
9. Built-in system menu, you can customize the number of calibrated points, TDS conversion factor, temperature unit, automatic or manual data locking, timing or manual shutdown and other 6 function parameters.
10. One-click reset (Reset), automatically restore the meter to the factory default settings.
11. Replaceable Electrode, reducing instrument maintenance and use costs.
12. Full waterproof performance to ensure complete protection of the instrument in harsh environments.
Principle
The meter measures the conductivity of the liquid through the Platinum Sensor and automatically performs temperature compensation to provide accurate readings. The built-in system supports a custom TDS conversion factor to convert conductivity to TDS values, and has an automatic terminal lock function to ensure the Stability of measurement results.
Applications
Research and education, water and wastewater treatment, environment monitoring, Eletroplating and printing industry, aquaculture and hydroponics, beverage industry and other industrial applications
Steps
1. Turn on the meter power.
2. Select conductivity or TDS Measurement mode as required.
3. Use 1 to 3 point buttons to calibrate and automatically identify the standard solution.
4. Immerse the Electrode in the liquid to be tested.
5. Wait for the reading to stabilize, and the automatic terminal lock function retains the reading.
6. Record or browse measurement results.
7. Clean the Electrode and turn off the power after use.
Notice
• Electrode cleaning to avoid contamination affecting Measurement accuracy.
• Conductivity detector standards specified when calibrating and using.
• Pay attention to the battery level and replace the AAA battery in time when the battery is low.
• Avoid use in environments beyond the Temperature Measurement range (0~ 60 ° C).
• The instrument has full waterproof performance, but it is still necessary to avoid long-term immersion in corrosive liquids.
• When using the one-click reset function, it will be restored to the factory default settings, and custom parameters will be lost.
• Regularly check Electrode status and replace replaceable Electrodes if necessary to maintain performance.
