Overview
The Bante531 Portable conductivity/Salinometer is a High Accuracy Portable Conductivity Meter with seawater and practical salinity measurement functions. The meter is suitable for outdoor measurement of liquid conductivity and salinity value. Measurement accuracy is 0.5% F. S, equipped with 1 to 5 point button calibrate and built-in system menu to customize 10 function parameters.
Features
1. High Accuracy Portable Conductivity Meter with Large Screen Backlit LCD
2.1 to 5 point button calibrated Conductivity detector standard
3. Optional Electrode constant (K = 0.1/1/10), standardized temperature (20 or 25 ° C), linear and pure water temperature compensation, seawater and practical salinity Measurement mode
4. Automatic temperature compensation to ensure accurate measurement over the full range
5. Automatic end point lock, keep stable Measured value for easy browsing or recording
6. Electrode diagnostics, check Electrode slope value (K)
7. The system menu can customize 10 function parameters such as the number of calibrated points, Stability standard, data locking mode, and automatic shutdown
8. One-click reset (Reset) automatically restores the meter to the factory default settings
9. Extended memory can store up to 500 sets of measurement data
10. Built-in clock automatically marks the date and time of stored data to comply with GLP specifications
11. USB Communication interface to send stored data to PC
12. Multi-mode power supply solution (battery, Power Adapter, USB port of computer) to ensure smooth application of the instrument
Principle
Conductivity detector Electrode measurement of liquid conductivity, using automatic temperature compensation technology to ensure accurate measurement over the full range. Linear and pure water temperature compensation modes are supported, Electrode constant and standardized temperature can be selected, and stable Measured value is retained through automatic end point locking function.
Applications
Water quality monitoring, geological and ecological research, chilled down tower and boiler water, printing industry, swimming pool and spa, agriculture and aquaculture, education and laboratory applications
Standards
GLP specification
Steps
1. Turn on the meter power
2. Select Measurement mode (conductivity or salinity)
3. Set Electrode constant, temperature compensation mode and other parameters as needed
4. Perform 1 to 5 point calibrating
5. Electrode immersion in the liquid to be tested
6. Read the result after the Measured value is stable
7. Can choose to lock data manually or automatically
8. Data is automatically stored and can be exported via the USB interface
Notice
• Make sure Electrode is clean and free of contamination before use
• Conductivity detector standards specified should be used when calibrating
• Electrode fully immersed in liquid during measurement
• Electrode status and slope values are checked regularly
• Turn off the power when not in use for a long time
• Avoid violent vibration or impact of the instrument
• Please use the specified Power Adapter or battery power
