Overview
GT-903 Pump Suction TVOC Gas detector is suitable for gas concentration detection in various industrial environments and special environments, using imported PID Light Ion Gas Sensor and microcontroller technology, Fast Response Speed, High Measurement accuracy, Good Stability and Repeatability, The whole machine performance ranks at the domestic professional level, the parameters can be customized by the user, the operation is simple, the instrument dust design, equipped with dust Filter, can be used in various harsh occasions.
Features
1. Imported PID Light Ion Gas Sensor and Microcontroller Technology
2. Fast Response, High Measurement accuracy, Stability and Repeatability
3. The performance of the whole machine ranks at the domestic professional level
4. Each parameter can be customized by the user, and the operation is simple
5. Instrument dust design, equipped with dust Filter, can be used in a variety of harsh occasions
6. The detection mode supports real-time detection and timing detection can be set
7. Storage mode supports real-time storage, timing storage can be set, and 120,000 groups of data can be stored
8. Support gas expansion 1-5 Sensors
9. Built-in micro air pump, Sampling method is pump suction
10. Optional Humidity measurement function
Principle
Sampling method using pump suction, built-in micro pump suction gas sample, through the imported PID light ion gas Sensor to detect TVOC concentration, combined with microcontroller technology to process data, Fast Response and High Accuracy measurement.
Applications
Industrial environment, special environment
Standards
GB3836.1-2010 "Explosive environments - Part 1: Equipment - General requirements", GB3836.4-2010 "Explosive environments - Part 4: Equipment protected by intrinsically safe" i "
Steps
1. Power on the detector
2. Set detection mode and storage mode as needed
3. Gas detection using pump suction sampling
4. View real-time or historical data on the screen
5. Customize the parameters
Notice
• Operating temperature range -30~ 60 ℃, relative humidity ≤ 95% RH non-condensing
• Operating Pressure Range -30Kpa~ 100Kpa
Powered by a 4000mA rechargeable polymer battery
• Explosion-proof mark is CNEx16.0537, Protection Rating is IP65
• The production license is Guangdong 00001052 (CMC metrology authentication)
