Overview
GT-903 pump suction hydrogen sulfide detector is a Portable single Gas detector of KORNO brand, which is suitable for hydrogen sulfide gas concentration detection in various industrial environments and special environments. The instrument adopts imported electrochemistry gas Sensor and microcontroller technology, which has the characteristics of fast Response speed, high Measurement accuracy, Stability and Repeatability. The whole machine performance ranks at the domestic professional level. Users can customize various parameters, simple operation, dust-proof design and equipped with dust Filter, which can be used in various harsh situations.
Features
1. Imported electrochemistry gas Sensor and microcontroller technology
2. Fast Response, High Measurement accuracy, Stability and Repeatability
3. Users can customize and set various parameters, and the operation is simple
4. Dust-proof design with Dust Filter for harsh environments
5. Supports 1-4 Sensor Extensions
6. With real-time storage and timing storage functions, it can store 120,000 sets of data
7. Protection Rating IP65, Explosion Proof Mark CNEx16.0538
8. Optional range: 0~ 50, 100, 500, 1000, 2000, 5000ppm
Principle
Electrochemical sensor is used to detect the concentration of hydrogen sulfide gas, and the environment gas is sucked into the instrument by the pump suction Sampling method. Sensor produces electrochemistry reaction on hydrogen sulfide gas, and the microcontroller processes the Sensor signal and calculates the gas concentration value. Finally, the measurement result is displayed on the screen.
Applications
Various industrial environments, special environments
Standards
GB3836.1-2010 "Explosive environment - Part 1: Equipment - General requirements", GB3836.4-2010 "Explosive environment - Part 4: Equipment protected by intrinsically safe type" i "
Notice
• Working ambient temperature range is -30~ 60 ℃
• Environmental humidity should be ≤ 95% RH, no condensation
• Operating Pressure Range -30Kpa~ 100Kpa
Powered by a 4000mA rechargeable polymer battery
• Instrument Protection Rating is IP65, Explosion Protection Mark is CNEx16.0538
• The production license number is Guangdong 00001052 (CMC metrology authentication)
