Overview
GT1000-VOC-Y organic solvent volatile gas, alcohol detector is suitable for gas concentration detection in various industrial environments and special environments. It adopts imported electrochemistry gas Sensor and microcontroller technology. It has the characteristics of fast Response speed, high Measurement accuracy, Stability and Repeatability. The performance of the whole machine ranks the domestic professional level. The instrument adopts dust-proof design and is equipped with dust Filter, which can be used in various harsh occasions. The parameters can be customized by users and the operation is simple.
Features
1. Detect VOC gas, range 0~ 100ppm, resolution 0.01ppm
2. Response Time ≤ 20s (T90), Linearity ≤ +/- 1%, accuracy ≤ +/- 3%
3. Supports 1-5 Sensor Extensions
4. Explosion-proof mark CNEx16.0537, Protection Rating IP65
5. Sampling method is pump suction, built-in micro air pump
6. 120,000 groups of data can be stored, supporting real-time detection, timing detection, real-time storage, and timing storage modes
7. Optional Temperature Humidity measurement, PM2.5 Laser Dust Particle Sensor, Micro Printer and other accessories
8. Operating temperature range -30~ 60 ℃, relative humidity ≤ 95% RH
9. Equipped with 4000mA rechargeable polymer battery
Principle
The instrument adopts imported electrochemistry gas Sensor and microcontroller technology, and performs pump-suction sampling through built-in micro air pump to detect and analyze the VOC gas concentration in the environment in real time.
Applications
Industrial environment, special environment
Standards
GB3836.1-2010、GB3836.4-2010
Steps
Step 1 Start the instrument
2. Set the detection mode as needed (real-time detection or timing detection)
3. Set the storage mode (real-time storage or timed storage)
4. Carry out gas concentration detection
5. Historical data can be viewed on the screen
6. Optional printer for data printing
Notice
• Operating temperature range of -30~ 60 ℃
• relative humidity should be ≤ 95% RH, no condensation
• Operating Pressure Range -30Kpa~ 100Kpa
• Make sure the battery is fully charged before use
• Regularly Check Dust Filter Status
• Use in places that meet explosion-proof requirements
