Overview
MUXUAN MXF-A2.2Q Small Batch Mixing Disperser is a new type of product designed according to the actual needs of production. It is mainly used for the pre-production experiments of paints, coatings, pigments, plastics, food and other liquid Stocks. It provides correct data for large-scale production and can also be used for small batch production. The product Processing capacity is 10-200L, and the explosion-proof type can be customized according to the material characteristics.
Features
1. High-performance motor, lower noise, smoother operation, ensuring high quality of the whole machine
2. CPU digital display Dynamic Rotation speed control, can realize timing fixed speed operation, the whole machine intelligent control
3. The hand lift is light and convenient, with a low failure rate, and the bottom of the frame is equipped with casters for easy movement
4. Mixing methods are diverse, paddle type, tooth plate type, blade type can be selected according to the process needs, and the replacement is simple and convenient
5. Explosion-proof design of the whole machine
Principle
The high-speed operation of the dispersion disc causes the material to form an annular flow, generating a strong vortex, which drops to the bottom of the eddy current in a spiral shape. Strong shear impact and friction are generated between the particles, achieving the functions of rapid dispersion, dissolving, uniform mixing and stirring.
Applications
Biological, Food, Coatings, inks, Adhesives, dyestuffs, pesticides
Standards
Full explosion-proof standard
Steps
1. Choose the appropriate mixing form according to the material characteristics
2. Put the material into the container, the maximum size of the container is 400mm in diameter and 560mm in height.
3. Adjust the position of the stirring head by hand lifting
4. Rotation speed and timing parameters
5. Start the device for decentralized mixing operation
6. Turn off the equipment after completing the operation, clean and maintain it
Notice
• Material viscosity should be ≤ 50000 cps
• Processing capacity range is 10-200L
• Power supply voltage is 220V
• The lifting method is manual lifting
• The equipment is fully explosion-proof, suitable for the corresponding explosion-proof environment
• Different mixing forms can be selected according to process needs
