Overview
MUXUAN MXF-A3 Small Batch Stirring Disperser is a MXF-A series pilot small batch frequency conversion Disperser, which is mainly used for the pre-production experiments of various paints, paints, pigments, plastics, food and other liquid Stocks. The product can provide correct data for large-scale production and can also be used for small batch production. Processing capacity is 10-70L, and explosion-proof types can be customized according to material characteristics.
Features
1. High-performance motor, lower noise, smoother operation, ensuring high quality of the whole machine.
2. CPU digital display Dynamic Rotation speed control, can realize timing fixed speed operation, the whole machine intelligent control.
3. Explosion-proof design of the whole machine.
4. The hand lift is lightweight and convenient, with a low failure rate. The bottom of the frame is equipped with casters for easy movement.
5. Mixing methods include paddle type, toothed disc type and blade type, and different mixing forms can be selected according to the needs of process production, and the replacement is simple and convenient.
Principle
The high-speed operation of the dispersion disc causes the material to form an annular flow, generating a strong vortex, which drops to the bottom of the eddy current in a spiral shape. Strong shear impact and friction are generated between the particles, achieving the functions of rapid dispersion, dissolving, uniform mixing and stirring.
Applications
Dispersion and mixing of materials for biological, food, paint, inks, Adhesive, dyestuff, pesticide and other industries
Steps
1. Choose the appropriate mixing form (paddle type, tooth plate type or blade type) according to the material characteristics.
2. Place the container under the rack to ensure that the maximum size of the container does not exceed 400mm in diameter and 560mm in height.
3. Use a hand lift to adjust the position of the dispersion disc to the appropriate height.
4. Set the required Rotation speed (0-1500rpm) and timing parameters through the CPU digital display control panel.
5. Start the device for decentralized and mixed operations.
6. After the operation is completed, turn off the power and clean the equipment.
Notice
The viscosity of the material should not exceed 50,000 cps.
• Processing capacity range is 10-70L, with water as standard.
• Ensure that the container size does not exceed 400mm in diameter and 560mm in height.
• Check that the power supply is 220V/380V before use and ensure that the equipment is grounded safely.
• Regularly check the lifting mechanism and mixing components to avoid malfunctions.
• For explosion-proof needs, customized explosion-proof models can be selected.
