PUSHEN SLZ 75/150um Cube Applicator wet film thickness 75/150μm application width 12.7mm

Name: PUSHEN SLZ 75/150um Cube Applicator wet film thickness 75/150μm application width 12.7mm
Brand: Pushen
SKU: NB018648
Price: 149.0 USD
Availability: InStock

$ 149.00Ex works

The device can provide 75/150μm two wet film thickness, application width of 12.7mm, accuracy of +/- 2/3μm, using 1Cr17N2 material, suitable for accurate single film and comparison of different formulations.

Model

Get Quote

Category : Film Applicator

Brand : Pushen

SKU : NB018648

Service :The delivery and service By NBCLab.Com

Overview

The PUSHEN SLZ 75/150um Cube Applicator is a professional film equipment with two specifications for accurate single-column film. Suitable for preparing samples with a straight line Drying Time Recorder or comparing different formulations simultaneously, each cube film applicator provides 2 film thicknesses.

Features

Available in two wet film thickness specifications (75/150μm) 2.The application width is 12.7mm 3. accuracy up to +/- 2/3μm 4. Made of 1Cr17N2 material 5. Cube design for easy operation

Principle

Spreader the specimen at a uniform speed by placing the Applicator on a fixed template to form a wet-film with a specified thickness. The Applicator must not move when sliding past the template to ensure accurate film thickness.

Applications

Spreader wet-film of specified thickness, measurement of sample hiding power, measurement of sample color, preparatory sample

Standards

ASTMD 823

Steps

1. Place the template on the platform and fix it 2. Applicator for wet film thickness 3. Place the Applicator on the short side of the template close to parallel or specified positions 4. Approximately 5 ml sample before Applicator 5. Press and hold both ends with your finger to slide at a constant speed of 150mm/s 6. After use, wash and dry with solvent and apply lubricating oil

Notice

• The sample must be fixed firmly and must not be moved • The sliding speed needs to be maintained at a constant speed of 150mm/s • It needs to be cleaned with solvent in time after use • After cleaning, dry and apply lubricating oil for maintenance

Type
Cube
wet film thickness
75/150μm
application width
12.7mm
accuracy
±2/3μm
material
1Cr17N2
standard
ASTMD 823
