JINGKELIAN QEY Paint film RDI Tester UV water vapor oxidation measurement equipment

Name: JINGKELIAN QEY Paint film RDI Tester UV water vapor oxidation measurement equipment
Brand: JingKeLian
SKU: NB018935
Price: 428.0 USD
Availability: InStock

$ 428.00Ex works

Using photo paper smooth surface combination technology, observing the imprint after applying a uniform load, the pressure range of the probe is 50-250N, and the diaMeter of the rubber probe is Φ 40mm, which can accurately evaluate the chalking grade of the paint film.

Model

Get Quote

Category : Paint Chalking Rate Tester

Brand : JingKeLian

SKU : NB018935

Service :The delivery and service By NBCLab.Com

Overview

JINGKELIAN QEY Paint film RDI tester is a special equipment for measuring the degree of chalking caused by the action of ultraviolet rays, water vapor, oxygen, etc. The instrument combines the paint film with the photo paper smooth surface. After applying the specified uniform load, take out the photo paper to observe the imprint and compare it with the standard pulverization rate grade sample to evaluate the paint film pulverization rate grade.

Features

1. Probe pressure range 50~ 250N, flexible adjustment 2. Probe pressure accuracy +/- 10%, accurate measurement 3. Rubber probe diameter φ 40mm, contact area standard 4. Probe Rubber Hardness 60 +/- 5A, in line with test requirements

Principle

The instrument adopts the method of smooth combination of paint film and photo paper. After applying the prescribed uniform load, the photo paper is taken out to observe its imprint. By comparing with the standard powder rate grade sample, the grade of paint film powder rate can be evaluated.

Steps

1. Combine the paint film with the smooth surface of the photo paper 2. Apply the specified uniform load 3. Take out the photo paper and observe the imprint. 4. Comparison with standard pulverization rate grade sample 5. Evaluate the paint film pulverization rate grade

Technical parameters Side pressure Range
50-250N
Lateral pressure accuracy
+/-10％
Rubber side head diameter
40mm
Hardness
Class 60 +/-5A

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
