Overview
Type 99-1A dual digital display high-power thermostatic magnetic heating Stirrer is an earlier product of the RONGHUA INSTRUMENT brand in the domestic market, and is widely used in various factories and biological product research. The product has passed the repeated test practice of the Beijing Institute of Biological Products, and is a relatively satisfactory Stirrer. It has the characteristics of large Power, low power consumption, no open flame, and no noise. It adopts permanent magnet DC motor, which has a long service life and no rusting. It can stir 10,000 ml of solution to achieve a satisfactory effect.
Features
1. Power, less power consumption
2. No open flame, no noise
3. Adopt permanent magnet DC motor, long service life
4. Not rusting
5. Can stir 10,000 ml of solution to achieve satisfactory results
6. Dual digital display design, easy to monitor parameters
7. High power heating capacity, Heating power 600W
8. Wide stirring speed range, 0~ 2600rpm stepless speed regulation
9. High temperature control accuracy, +/- 1 ℃
Principle
The product drives the stirrer to swirl/spin in the container through magnetic coupling to achieve uniform stirring of the solution; at the same time, the working plate is thermostatic controlled by the heating system to ensure stable operation within the set Temperature range. The dual digital display system displays the stirring speed and temperature parameters in real time, which is convenient for users to monitor and adjust.
Applications
Research on various plants and biological products
Steps
1. Connect the device to a single-phase AC 220V +/- 10V 50HZ power supply
2. Place the container to be stirred on the 300 * 300mm working plate
3. Set the required stirring speed and adjust it within the range of 0~ 2600rpm through stepless speed regulation
4. Temperature range between RT +~ 100 ℃
5. Start the equipment to start stirring and heating
6. Monitor real-time parameters through dual digital displays and adjust if necessary
