RONGHUA INSTRUMENT JJ-1 (100W) precision powerbasic stirrer permanent magnet DC motor stepless speed regulation

Name: RONGHUA INSTRUMENT JJ-1 (100W) precision powerbasic stirrer permanent magnet DC motor stepless speed regulation
Brand: RONGHUA
SKU: NB020473
Price: 135.0 USD
Availability: InStock

$ 135.00Ex works

Adopting permanent magnet DC motor with augmented speed line to achieve 0-3000rpm stepless speed regulation, with 100W Power output, smooth operation and no need to replace carbon brushes, medium speed stirring can reduce vibration.

Model

Get Quote

Category : Laboratory Mixer

Brand : RONGHUA

SKU : NB020473

Service :The delivery and service By NBCLab.Com

Overview

RONGHUA INSTRUMENT JJ-1 (100W) precision booster powerbasic stirrer is developed and produced for the needs of new scientific research projects in modern laboratories. It adopts permanent magnet DC motor and professional booster speed line, and has the characteristics of stable Rotation speed, large torque, low noise, and no need to replace carbon brushes.

Features

1. Adopt permanent magnet DC motor 2. Equipped with professional augmented speed lines 3. Rotation speed is stable 4. High torque 5. Low noise 6. No need to replace the carbon brush 7. Stepless speed regulation 8.0~ 3000rpm wide speed range 9.0~ 120Min timing function

Principle

The Stirrer is driven by a permanent magnet DC motor and combined with a professional force-increasing and stable speed circuit to achieve stable Rotation speed output and strong stirring torque, ensuring a smooth and reliable stirring process.

Steps

1. Support the stirringrod on the motor shaft clamp 2. Adjust the speed knob to the lowest speed position 3. Place the solution to be stirred in the center of the stirringrod 4. Turn on the power switch 5. When timing operation is required, select the required time or normally open

Notice

• Be sure to ground the wire when using it • If you find that the stirringrod is not centered and the stirring is unstable during work, please turn off the power supply and adjust the support chuck to make the stirringrod concentric • Medium speed stirring can reduce vibration and prolong service life • Instruments should be kept drying

Power supply Voltage
220V 50HZ
Motor Power
100W
speed control
Start~ 3000 rpm stepless speed regulation
