TQC sheen SH0530 coating Scratching Tester 20N ISO 1518-1

Name: TQC sheen SH0530 coating Scratching Tester 20N ISO 1518-1
Brand: TQC sheen
SKU: NB020785
Price: 10084.0 USD
Availability: InStock

$ 10084.00Ex works

The device uses a 35mm/s scribe traverse speed, a load range of 20N, and can clamp a test board up to 100x150x1.6mm. It contacts the substrate through a voltMeter indicator tool to achieve failure assessment from trace to damage.

Model

Get Quote

Category : Scratch Tester

Brand : TQC sheen

SKU : NB020785

Service :The delivery and service By NBCLab.Com

Overview

The TQC Sheen SH0530 coating surface scratch resistance tester is a mechanized Scratching Tester for coating Hardness assessment based on the scratch resistance method. The instrument achieves varying degrees of failure from trace to damage by clamping the test plate and moving slowly while scraping the surface with a stylus or alternative tool according to the test procedure applying a specified or variable load. The voltmeter indicates the contact of the tool with the metal sample substrate, with a maximum panel size of 100x150x1.6mm (0.3mm coating).

Features

1. Mechanized design ensures a stable and reliable testing process 2. Designated or variable loads can be applied to achieve different degrees of failure 3. The voltmeter indicates the contact status between the tool and the substrate in real time 4. ISO 1518-1 compliant weight setting Choice of weight groups specified by ISO 1518

Principle

The instrument obtains varying degrees of failure from trace to damage by clamping the test plate and moving slowly while scraping the coated surface with a stylus or alternative tool, applying a specified or variable load according to the test procedure. The voltmeter is used to indicate the contact status of the tool with the metal sample substrate to ensure the accuracy of the test.

Standards

ISO 1518-1

Steps

1. Clamp the test plate to the instrument 2.Set the traverse speed to 35mm/s 3. Select and apply the load according to the test procedure 4. Start the instrument for scratch test 5. Observe the contact status between the voltmeter indicator tool and the substrate Step 6 Record test results

Notice

• The maximum size of the test board shall not exceed 100x150x1.6mm. • The maximum thickness of the coating shall not exceed 0.3mm. • Load range must not exceed 20N • Power supply voltage must be 230VAC 50HZ • Make sure the instrument is well grounded before operation • Avoid touching moving parts during testing

Scribing traverse speed
35mm/s
Maximum Size of test sample
100x150x1.6mm
Maximum thickness of test sample
0.3mm
Meet the standard
ISO 1518-1
Configure weight
20N
Power supply Voltage
230VAC, 50HZ
