Overview
HENGLI PX-130 electric incubator is suitable for microbial foster and other industries, and is the equipment required for biological, agricultural and scientific research experiments. Using ALLHEAT ™ cavity preheating technology to meet different temperature requirements and provide a constant temperature environment, with Pro-lnsulation ™ thermal insulation technology to ensure the smooth progress of sample experiments and foster, can provide Chinese/English IQ, OQ, PQ and a variety of verification services.
Features
1. ALLHEAT ™ cavity preheating technology, the heating elements are evenly distributed to ensure uniform temperature and low energy consumption.
2. ALLFLOW ™ air circulation system, shorten the temperature recovery time after opening the door, and the wind speed can be adjusted with fan switch.
3. ALLSENS ™ microcomputer PID control technology, LCD large screen display, adaptive PID precise temperature control, user password control, RS485 interface can connect multiple devices.
4. Pro-Insulation ™ isolation insulation technology, high-density insulation materials, silicone door seals and isolation door hinge design to ensure sealing.
5. Original imported PT100 temperature transducer, Response is fast, self-heating effect is small.
6. Ergonomic Structure Design, Arc Appearance, Adjustable Movable Network Shelf, Double Door Design.
7. Easy to clean, the liner is least spliced, and the activities can be extracted from the shelf.
8. Easy maintenance, control appliance diagnostic function, and separate installation of electrical components.
9. Safety protection, multiple over-temperature protection, sound and light alarm, UL certification for electronic components.
Principle
Using ALLHEAT ™ cavity preheating technology, the heating elements are evenly distributed around the inner tank for preheating. Through heat transfer and forced fan convection, the temperature at each point in the cavity accurately reaches and maintains the set value to ensure uniform temperature distribution. With ALLFLOW ™ air circulation system, the temperature is quickly restored and the temperature in the cavity is continuously stable after opening the door.
Applications
Microbial fostering, biological experiment, agricultural experiment, scientific research experiment
Standards
European Union CE safety certification, Australian AS/NZS3350 standard, German DIN 12880 Class 3.1 standard
Steps
1. Connect the power supply to AC 220V/50Hz.
2. Select Chinese/English display through the LCD screen, and set parameters such as temperature and time.
3. Use the user password control to confirm the setting operation.
4. Start the device and monitor the running status.
5. Optional microcomputer software remote control.
Notice
• Ambient Temperature should be maintained at 10~ 30 ℃.
The working environment humidity should be below 70% RH.
• Regularly clean liners and shelves to maintain hygiene.
• Pay attention to the electrical components located at the back of the box during maintenance.
• Pay attention to over-temperature protection alarms during use and deal with abnormalities in a timely manner.
