Overview
The HENGLI LC-250 light chamber is a device specially designed for biological tissue, cell foster, seed germination, plant cultivation, small animal and insect feeding, etc. It can provide simulation of daytime and night Illumrination degree changes and climate conditions, supports multi-stage step programming control, and has passed the European Union CE safety certification and enjoys a 2-year mass warranty.
Features
1. ALLCOLD ™ equilibrate refrigeration technology, equipped with automatic defrosting and environmentally friendly refrigerant, energy saving and efficient.
2. ALLFLOW ™ air circulation system to ensure rapid temperature recovery and stability, and adjustable wind speed.
3. ALLSENS ™ microcomputer PID control technology, supports Chinese and English display, adaptive PID control and remote monitoring.
4. Original imported PT100 temperature transducer, Response is fast, self-heating effect is small.
5. Double-decked isolation and thermal insulation technology to reduce energy consumption, and the inner isolation door is designed to maintain a consistent temperature.
6. Ergonomic structural design, including circular arc Appearance, movable Shelf and double door, comfortable operation.
7. Easy to clean and maintain, less splicing of the liner, and separate installation of electrical components.
8. Multiple safety protection, including over-temperature protection and sound and light alarm, in line with international standards.
9. Pro-Bright ™ professional lighting system, simulates natural light, Illumrination degree can be adjusted, and cooperates with humidification system for climate simulation.
Principle
The light chamber precisely adjusts the temperature through the ALLSENS ™ microcomputer PID control technology, combined with the ALLFLOW ™ air circulation system to ensure uniform and stable temperature in the chamber. The ALLCOLD ™ cooling technology uses an equilibrate solution and a fast heat pump to defrost for continuous operation. The Pro-Bright ™ lighting system simulates day and night light changes and compensates for heat through the control system to maintain a constant temperature.
Applications
Biological tissue fostering, cell fostering, seed germination, plant planting, small animal feeding, insect feeding
Standards
National standard, Australian AS3100, US FDA, EN, ICH (cGMP/ICH/380/95/Q1A and Q1B), European Union CE safety certification, German DIN 12880 Class 3.1 standard
Steps
Connect the power supply and ensure that the voltage is AC 220V/50Hz.
2. Select the language (Chinese or English) through the LCD display, and set parameters such as temperature and Illumrination degree.
3. Use the active Shelf to adjust the sample placement and adjust the light level as needed.
4. Start the device, monitor the running status, and connect multiple devices through the RS485 interface for real-time monitoring.
5. After the operation, shut down the equipment and perform cleaning and maintenance.
Notice
• Ambient Temperature should be kept at 10~ 30 ℃ and humidity below 70% RH.
• Avoid setting temperatures below 10 ° C in no-light conditions.
• Regularly check the over-temperature protection function to ensure that the sound and light alarm is normal.
• Pay attention to the maintenance of liners and Shelves when cleaning, and avoid the use of corrosive cleaners.
• During equipment maintenance, ensure that the power is disconnected and the electrical components are located at the back of the box.
• When using remote control software, ALLSENS ™ programmable software is required.
