Overview
MA6 Portable Glossiness Meter is a JND brand of High Accuracy general gloss measurement instrument, designed and manufactured with reference to international standards ISO 2813 and Chinese national standards GB/T13891, GB9754, GB7706, GB8807, technical parameters in line with ASTM D2457, ASTM D523 standards, performance indicators meet the national standard JJG 696-2002 secondary machine requirements, Gloss Traceability from Shanghai Institute of Measurement and Testing Technology (SIMT) gloss benchmark.
Features
1. Fully intelligent boot self-calibrating, High Accuracy, High stability, immediate test, simple and convenient operation.
2. The new intelligent error compensation device design allows users to easily adjust without returning to the factory.
3. The measurement data has passed the trusted certification for five consecutive years and can be Traceability to the SIMT National Measurement verification center.
4. National level standard black (high) white (low) calibration plate, in line with national standards, can easily pass Measurement verification.
5. Adopt professional optical path design, stable and reliable measurement data, minimal Inter-instrument Agreement and excellent reproducibility.
6. Ergonomic shell, high-end mold one-time molding, anti-skid, lightweight, and resistant to a variety of solvents (patent number: ZL 2014 3 024 2920.5).
7. Pay attention to safety with high-end nonconductive shell, high safety factor, to avoid electric shock.
8. The power supply adopts imported high-end management chips, and the maximum charge can reach 80 hours of continuous measurement, which is effective in the industry.
9. Adopt imported non-mechanical three-proof power switch, which has a long lifespan and a good feel.
10. Elliptical angle, soft surface probe design, effectively prevent the measurement process from scratching the measured object.
Principle
The MA6 Glossiness Meter evaluates the material's Gloss performance by measuring the gloss value of the reflected light on the surface, using 60 ° Measurement Angles, the light spot size is 9 * 18mm, the elliptical measurement port design ensures High Accuracy and stability, and the intelligent self-calibrating function ensures measurement accuracy.
Applications
Paints coatings, decoration materials, building materials, plastic materials, bamboo and wood products, Pottery and porcelain products, metal polishing surface, Eletroplating surface, painting layer, leather products, film paper, Printing ink, Stone and many other fields of material products and various Non-metallic surface gloss measurement.
Standards
ISO 2813、GB/T9754、ASTM D2457、ASTM D523、GB/T13891、GB/T7706、GB/T8807、JJG 696
Steps
1. Turn on the power switch of the instrument.
2. The instrument automatically starts and self-calibrates.
3. Align the measurement head with the measured surface.
4. Press the measurement button for gloss measurement.
5. Read the measurement value on the LCD display.
Notice
• Instrument operation temperature range is 15~ 40 ℃, relative humidity < 85%, no condensation.
• Storage temperature range is -10~ 60 ℃.
• Make sure the battery is fully charged before use, and the power supply is 1.2~ 1.5V AA (No. 5) rechargeable or alkaline battery.
• Avoid scratching the test object during measurement, using elliptical angle and soft surface probe design.
• Regularly calibrate with standard calibration plates to ensure measurement accuracy.
