Overview
The HMS-15 multi-point Magnetic Stirrer is a multi-point digital Magnetic Stirrer of the BDJK brand, with 15 working positions. The product has a novel and beautiful design, easy operation, continuous adjustable Stir speed, and smooth and quiet operation of the instrument. The heating plate surface temperature can be arbitrarily set within the range of room temperature to 200 ° C, and the sample temperature can be heated up to 100 ° C. The heating module adopts nano-thermal energy technology, which heats quickly, has a large heating area, and is evenly heated. It is suitable for experiments such as large-scale sample screening, foster, sample condensing, and solvent evaporation.
Features
1. The heating module adopts nano-thermal energy technology, no mechanical heating components, can be dry burned, no electromagnetic field interference and harm, large heating area, uniform heating, and extremely fast heating
2. Stir 1-500ml standard or non-standard containers of various shapes and sizes
3, using DC motor, stable performance, low noise, long life, low speed stable, high speed strong
4. The fuselage is made of aluminum oxide alloy, and the appearance design is novel and beautiful
5. The working panel adopts German Microcrystalline Pottery and porcelain, acid-resistant, alkali-resistant, high temperature-resistant, easy to clean
Principle
The Magnetic Stirrer uses a DC motor to drive the magnetic Stirr swirl/spin to realize the Stir of the sample. The heating module uses nano-thermal energy technology to generate heat through electrothermal conversion, which is evenly transferred to the working panel to heat the sample in the container.
Applications
Biological, petroleum, chemical, environmental protection
Steps
1. Place the Stirrer on a stable workbench
2. Connect the power cord to a suitable power outlet
3. Place the container containing the sample on the working panel
4. Stir into the container
5. Turn on the power switch
6, according to the need to adjust the stirring speed knob to the required speed
7. If heating is required, set the heating temperature
8. After the experiment is completed, turn off the power switch
9. Clean the work panel after the equipment is chilled down
Notice
• Power frequency is consistent with equipment requirements before use
• Do not touch the heating panel when the equipment is working to avoid burns
Do not use the equipment in a humid environment
• Please disconnect the power supply when cleaning, and wait for the equipment to chill down completely
• Do not use sharp objects to scrape the work panel
• Equipment Ambient Temperature should be within the range of 5 ℃~ 40 ℃
• The environment humidity should be less than 90%
• Do not exceed the maximum capacity of the device Stir 500ml
• Stir length should not exceed 40mm
