TQC Sheen AB3702 Film Applicator, Double Sided 70/150μm

Name: TQC Sheen AB3702 Film Applicator, Double Sided 70/150μm
Brand: TQC sheen
SKU: NB022280
Price: 597.0 USD
Availability: InStock

$ 597.00Ex works

Cube Applicator can achieve 70/150μm double-sided Film thickness Spreader, through the hardening process to ensure that the overall uniform hardening, Spreader width 12mm, guide plate design for narrow Glass panel direct use.

Model

AB3702

Get Quote

Category : Film Applicator

Brand : TQC sheen

SKU : NB022280

Service :The delivery and service By NBCLab.Com

Overview

The TQC sheen AB3702 Film Applicator is a cube applicator for applying films of uniform Film thickness. The product can be applied with two predetermined Film thicknesses according to customer requirements, making it ideal for painting on Drying Time Recorder's test plates. The cube applicator comes standard with a guide plate, which does not require additional caster guides when used with a narrow Glass panel (AB3602). The guide plate ensures direct stretching on the narrow Glass panel and is easy to remove.

Features

1. Made of ASAB Stavax ESR medical grade stainless steel tool steel, hardened hardness HRC 55 for zero degree vacuum hardening 2. Equipped with removable guide plate to simplify the operation process 3. Double-sided design can provide two different wet film thicknesses 4. Adopt through hardening process to ensure that the metal is evenly hardened throughout the workpiece and prolong the service life 5. High Accuracy Spreader, accuracy up to +/- 2μm

Principle

The Film Applicator scrapes evenly on the test surface through a cube structure to form a wet-film of predetermined Film thickness. The guide plate ensures stable stretching on the narrow Glass panel for accurate Spreader. The whole tool steel material is uniformly hardened through the hardening process to ensure the accuracy and durability of long-term use.

Applications

Paint Testing and Drying Time Recorder

Standards

ASTM D823

Steps

1. Prepare test plates and coatings 2. Select applicator Film thickness according to requirements 3. Install the guide plate to the applicator (e.g. using a narrow Glass panel) 4. Scrape the paint evenly on the test board 5. Clean and store equipment

Notice

• Make sure the applicator is clean and free of contamination before use • Avoid hard object collisions to avoid affecting accuracy • Regularly check whether the guide plate fixing screw is loose • Avoid wet environments when storing • Only for professional operation

Type
multi-faceted
Film width
12mm
accuracy
+/-2μm
material
ASAB Stavax ESR Medical Grade Stainless Steel Tool Steel, Polished
standard
ASTM D823
Size
25*24*24mm
net weight
65g
hole diameter
15mm

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
