Overview
Sanenchi NR10QC color difference meter is an economical general-purpose color difference meter designed for users who pursue affordable prices and need general product color difference measurement. The instrument adopts a vertical structure with a measurement diameter of 4mm, can automatically correct black and white when turned on, and has Stability and Reliability. It is a cost-effective choice in China color difference meters.
Features
1. Low price;
2. High short-term Repeatability accuracy: Delta E ≤ 0.03;
3. Equipped with dual positioning functions of light and cross;
4. Equipped with rechargeable lithium-ion batteries, there is no need to purchase batteries repeatedly.
5, φ 4mm measurement diameter, portable structure, suitable for more measurement occasions;
6, dark blue mainstream shape, color box Fast Encasement, easy transportation;
7. Built-in whiteboard parameters, no need for black and white board correction.
8. It doesn't need to be connected to a computer to start up and use immediately. The operation is simple.
Principle
The NR10QC color difference meter is developed according to the relevant standards and national standards of CIE (International Commission on Illumination), using imported key components, through 8 °/d lighting mode and LED Illuminant, combined with silicon photodiode sensor for Color measurement to ensure accurate and stable.
Applications
Color quality control and color difference detection in Spinning & weaving, printing and dyeing, clothing, footwear, leather, chemical, plastic, plastic, pigment, paints, inks, printing, Hardware, photography, toys, food and other industries
Standards
CIE No.15、GB/T 3978
Steps
1. It is ready to use when powered on, no need to connect to a computer;
2. The instrument automatically performs black and white correction.
3. Use lighting and cross positioning functions to align the measurement area;
4, the color difference measurement, the results are automatically displayed.
Notice
* Operating Ambient Temperature is 0~ 40 ℃, Storage Ambient Temperature is -20~ 50 ℃;
* Ensure that the battery is well charged and avoid use in extreme environments;
Periodically check Instrument Repeatability and Inter-instrument Agreement to maintain Measurement accuracy;
Store properly after use to avoid collisions and moisture.
