Overview
The NIRUN NTV-T2R viscosity temperature control machine is a device that integrates viscosity measurement and temperature precision control, breaking through the traditional split machine mode. The system consists of a 7-inch Touchscreen host, a small sample adapter, an SC4 rotor and a temperature controller. It supports shear rate and shear stress display. The sample dosage is only 2-16ml, and the electric lift is accurately positioned and easy to operate. The temperature control adopts semiconductor technology with an accuracy of +/- 0.1 ° C, which can be controlled by the host or software to ensure accurate experimental results.
Features
1. Integrated viscosity measurement and temperature control in one, breaking through the limitations of the split machine; 2.7 inch wide Touchscreen host, intuitive operation; 3. Small sample adapter (SSR) and SC4 rotor, small sample consumption (2-16ml), accurate measurement; 4. Electric lifting system, precise positioning; 5. Temperature control accuracy +/- 0.1 ℃, using semiconductor technology; 6. Support stepless speed measurement, input speed directly display full scale and shear rate; 7. With password protection temperature and viscosity correction coefficient, allowing users to correct themselves; 8. Support simple programming to control rheological Linear dispersion; 9. External U disk data storage, single point, continuous, regular storage mode optional; 10. Small sample cartridge easy to load and unload, easy to clean.
Principle
The viscosity temperature control all-in-one machine is combined with the SC4 rotor through a small amount of sample adapter. The viscosity measurement is carried out in the sample sleeve. The cylindrical geometry ensures accurate results. The temperature control is realized by the semiconductor and the built-in automatic optimization program. The temperature control accuracy is +/- 0.1 ℃. The temperature inhomogeneity is reduced through the rotor Stir and a small amount of samples, and the thermostatic time is shortened. The system supports stepless speed change, which directly reflects the shear rate and stress, and can be programmed to control the rheological Linear dispersion.
Applications
Suitable for experiments requiring viscosity measurement and temperature control, product performance testing, rheology research, chemical, pharmaceutical, food, coatings and other fields
Steps
1. Connect the power supply and start the device; 2. Set test parameters such as speed and temperature through Touchscreen; 3. Install a small amount of sample adapter and SC4 rotor, add 2-16ml sample; 4. Use the electric lifting system to accurately locate; 5. Start measurement, the system automatically controls temperature and viscosity; 6. Save data through U disk or software; 7. After the test is completed, remove the sample cartridge for cleaning.
Notice
* Ensure that the power input is AC100-240V, 50Hz/60Hz; * The sample dosage is controlled within the range of 2-16ml; * Pay attention to the temperature range -1~ 150 ° C during operation to avoid exceeding the limit; * Clean the sample cylinder and rotor in time after use; * Correct the temperature and viscosity coefficient with reliable data support; * Avoid operating in humid or extreme environments; * Regularly check the equipment connection and accuracy.
