Overview
The NIRUN NTV-T2HA viscosity temperature control machine is a Rheometer system that integrates viscosity measurement and temperature precision control. It is composed of a 7-inch Touchscreen host, a small sample adapter, an SC4 rotor and a temperature controller. The sample consumption is only 2-16ml. It supports shear rate and shear stress display, stepless speed measurement, electric lift and U disk data storage. The temperature control accuracy is +/- 0.1 ° C. It is suitable for predicting product behavior and ensuring experimental accuracy.
Features
1. Integrated design, integrated viscosity measurement and temperature control, breaking through the traditional split machine mode; 2.7 inch wide Touchscreen operation, support Chinese interface; 3. SC4 rotor cylindrical geometry, providing accurate viscosity measurement; 4. Sample consumption is small (2-16ml), short thermostatic time; 5. Electric lifting system, precise positioning; 6. Support stepless speed measurement, input speed directly display full scale and shear rate; 7. Built-in password protection temperature and viscosity correction coefficient, allowing users to correct themselves; 8. Support external U disk data storage, single point, continuous, timing storage mode optional; 9. Temperature control accuracy +/- 0.1 ℃, using semiconductor and built-in automatic optimization program; 10. Temperature can be controlled by host or DV software, flexible operation.
Principle
The viscosity temperature control machine performs viscosity measurement through the cylindrical sample sleeve of the small sample adapter (SSR) and the SC4 rotor. Stir action of the rotor reduces the temperature inhomogeneity of the sample. The temperature control is realized by the semiconductor and the built-in automatic optimization program, and the precise thermostatic ensures the accurate experimental results. The system can display the shear rate and shear stress, support the continuously variable speed measurement, and accurately locate the sample through the electric lifting system.
Applications
Viscosity measurement, temperature control, Linear dispersion analysis, product performance prediction
Steps
1. Connect the power supply and enter AC100-240V; 2. Turn on the host and use the 7-inch Touchscreen to set the parameters; 3. Install a small amount of sample adapter and SC4 rotor; 4. Add 2-16ml sample; 5. Select the speed (0.1-200 rpm) or control through DV software; 6. Start the measurement, and the system will automatically lift and position; 7. Select single point, continuous or regular data storage as needed; 8. Use the U disk to export the data.
Notice
* Ensure that the Power frequency is within the range of AC100-240V; * The sample dosage is controlled at 2-16ml; * Check whether the rotor is firmly installed before use; * Avoid operating outside the extreme temperature range (-1~ 150 ° C); * Clean small sample cylinders with care; * Correct temperature and viscosity coefficients based on reliable data; * Ensure that the U disk is compatible when storing data; * Follow equipment safety guidelines during operation.
