Overview
SANFA DHG-9240 electric thermostatic blast drying oven is a equipment suitable for industrial and mining enterprises, laboratories, R & D institutions and other places, for drying, baking, wax melting and sterilizing. The box is welded with good steel plate, the surface is electrostatic sprayed, the working room is sprayed with high temperature silver paint, the door has an observation window or double door structure, which has the characteristics of energy saving and beauty.
Features
1. The inside and outside of the box are welded with good steel plates, the surface is electrostatic sprayed, the working room is mirror stainless steel or high temperature resistant silver paint, the door has an observation window or a double door structure, and the shape is novel, beautiful and energy-saving.
2. Microcomputer intelligent digital display temperature controller, accurate and reliable temperature control, while displaying the set temperature and the temperature inside the box, with overheating, leakage, Sensor fault alarm function, timing function (optional intelligent LCD temperature controller).
3. Adopt low noise fan and suitable air duct to form hot air circulation system, dry hot air directly through the heated object drying, sterilizing.
4. In addition to the above functions, the upgraded liquid crystal display temperature controller also has programmable temperature control, can be equipped with RS-485 interface, can be connected to the recorder and computer, and can record the change of temperature parameters (optional).
Principle
The equipment adopts a low-noise fan and a suitable air duct to form a hot air circulation system, which directly passes through the heated object through dry and hot air for drying and sterilizing. The microcomputer intelligent temperature control instrument ensures precise temperature control and realizes efficient hot air circulation.
Applications
Industrial and mining enterprises, laboratories, R & D institutions
Steps
Connect the power supply and ensure that the voltage is 220V 50Hz.
2. Open the equipment door and place the items to be processed on the shelf.
3. Set the required temperature (Temperature range RT + 10~ 250 ℃) and timing time (1~ 9999min).
4. Start the equipment and the hot air circulation system starts to work.
5. Monitor the temperature display, and the device automatically controls the temperature and alarms abnormalities.
6. After the timing is over, turn off the device and remove the items.
Notice
• Power frequency check before use to meet 220V 50Hz requirements.
• Ensure that items are placed evenly in the workplace to avoid affecting Temperature Uniformity.
• Pay attention to overheating, leakage and Sensor fault alarm functions, and deal with abnormalities in time.
• Regularly clean and maintain equipment to maintain performance.
When selecting the RS-485 interface, it is necessary to connect the recorder or computer correctly.
