Overview
HP-050A drying oven/incubator (dual-use) is a new generation of laboratory trial products developed by integrating the company's many years of production experience and introducing foreign professional technology. The product has a wide range of trials, drying and fostering dual-use, is simple and convenient, high-quality and reliable, and directly helps Universities & colleges, scientific research and production, enabling users to save time and improve work efficiency.
Features
1. Mirror stainless steel liner, four corners and a half arc, easy to clean, adjustable shelf spacing
2. Intelligent microcomputer controller, accurate and reliable temperature control, and with over-temperature, Sensor failure, leakage, overcurrent and other protection functions, with sound and light alarm function, with timing function
3 drying, foster replacement operation is simple and convenient, intelligent control
4. Forced warm air circulation design to ensure uniform temperature in the studio
5. Using silicone rubber sealing strip and double-decked Glass inner observation window, easy to observe
6. Optional RS-485 interface can be connected to an embedded printer, which can record changes in temperature parameters (optional)
Principle
The forced warm air circulation design is adopted, and the temperature is precisely controlled by the intelligent microcomputer controller to ensure the uniform distribution of the temperature in the studio. Through the structural design of mirror stainless steel liner and silicone rubber sealing strip, the intelligent control of drying and fostering functions is realized.
Applications
Universities & colleges, research, production
Steps
1. Power frequency 220V 50Hz
2. Choose drying or foster mode as needed
3. Temperature range (foster: RT + 5~ 80 ℃; drying: 80~ 250 ℃)
4. Adjust the shelf spacing
5. Set Timer Range 1-9999min
6. Start the device to work
Notice
• Working Ambient Temperature should be kept within the range of RT + 5~ 35 ℃
• Power frequency is 220V 50Hz before use
• Note that the equipment has protection functions such as over temperature, Sensor failure, leakage, overcurrent, etc., and should be dealt with in time when there is a sound and light alarm
• Observing the sample through a double-decked Glass inner observation window
• Optional RS-485 interface to connect to embedded printer to record temperature parameter changes
• Keep the mirror stainless steel liner clean and clean the box regularly
