Overview
HP-140A drying oven/incubator (dual-use) is a new generation of laboratory trial products developed by integrating the company's many years of production experience, adapting to user requirements, and introducing foreign professional technology. The product has a wide range of trials, drying, fostering dual-use, simple, convenient, high-quality and reliable, and directly helps Universities & colleges, scientific research and production, enabling users to save time and improve work efficiency.
Features
1. Mirror stainless steel liner, four corners and a half arc, easy to clean, adjustable shelf spacing.
2. Intelligent microcomputer controller, accurate and reliable temperature control, and with over-temperature, Sensor failure, leakage, overcurrent and other protection functions. With sound and light alarm function, with timing function.
3 drying, foster replacement operation is simple and convenient, intelligent control.
4. Forced warm air circulation design to ensure uniform temperature in the studio.
5. Using silicone rubber sealing strip and double-decked Glass observation window, easy to observe.
6. Optional RS-485 interface can be connected to an embedded printer to record changes in temperature parameters (optional).
Principle
The product precisely controls the temperature through an intelligent microcomputer controller, and adopts a forced warm air circulation design to ensure uniform temperature in the studio. The drying and foster functions can be realized through simple replacement operations, and a variety of protection functions ensure safe and reliable operation.
Applications
Universities & colleges, research, production
Steps
1. Power frequency 220V 50Hz.
2. Select drying or foster mode as needed.
3. Set the temperature parameters through the intelligent microcomputer controller (foster: RT + 5~ 80 ° C; drying: 80~ 250 ° C).
4. Set Timer Range 1-9999 minutes.
5. Start the device and monitor the running status.
Notice
The Ambient Temperature should be kept within the range of RT + 5~ 35 ℃.
Power frequency meets 220V 50Hz requirements before use.
Pay attention to the protection function status such as overtemperature, Sensor failure, leakage, overcurrent, etc.
The observation window is made of double-decked Glass, so pay attention to protection when using it.
Optional RS-485 interface needs to be configured separately.
