Overview
Turbidity meter is an instrument used to measure the scattering and attenuation of light generated by insoluble particulate matter suspended in water (or transparent liquid), and to characterize the content of these suspended particulate matter by Basis Weight. Widely used in water plants, food, chemical industry, power plants, metallurgy, environmental protection, beverages, wine and other industries, it is a commonly used laboratory instrument.
Features
1. Using microcomputer technology, color LCD Touchscreen display, operation is more intuitive and convenient
2. Using the scattering-transmission light measurement principle, the ratio is calibrated
3. Automatic range switching, support multi-point calibrating
4. With average measurement function; can store 1000 sets of test data, data can be saved, printed, uploaded
5. Time and date setting functions, in line with GLP specifications and ISO7027 industry standards
6. USB communication interface and U disk read data, support connecting to PC for data upload
Principle
Using scattering - transmitted light measurement principle, by measuring the degree of scattering and attenuation of light suspended in water (or transparent liquid) insoluble particulate matter generated, Basis Weight characterization of the suspended particulate matter content.
Applications
Water plant, food, chemical industry, power plant, metallurgy, environmental protection, beverage, wine making
Standards
GLP specification, ISO7027 industry standard
Steps
1. Prepare sample bottle (φ 25mm × 95mm) and sample capacity (30ml-40ml)
2. Operation settings through color LCD Touchscreen
3. Select the measurement mode, the instrument supports multi-point calibrating and automatic range switching
4. Start the measurement, the instrument uses the principle of scattered-transmitted light for turbidity detection
5. Data can be stored, printed, or uploaded to a PC via a USB interface
Notice
• Power frequency 220V +/- 22V, frequency 50Hz +/- 1Hz before use
Sample capacity should be in the range of 30ml-40ml
• Periodically calibrated, supports up to 5 point correction
• Instrument net weight 6kg, pay attention to safety when handling
• Use the matching φ 25mm × 95mm sample bottle for measurement
