Overview
NIRUN NTV-P2HA intelligent Viscometer is a precision measuring instrument with 7 inch wide Touchscreen, with rich display information and convenient operation experience. It supports a variety of viscosity units and measurement modes, suitable for viscosity measurement in glues, latex, solvent adhesives, polymer solutions, petroleum, paints, solvents, cosmetics, milk products, products, fruit juices and other fields.
Features
1.7 inch wide Touchscreen, easy to operate, rich display information
2. Optional DV data collection and program control software can measure rheological characteristics, and the screen directly displays rheological Linear dispersion
3. Display shear rate and shear stress metrics
4. Anti-static shell, metal lifting rod design
5. Built-in RTD Temperature Probe
6. ARM chip processor, processing data faster
7. Durable new small shaft design
8. Powerful human-machine interaction interface
9. Gigabit network port data communication transmission, fast and reliable data transmission
10. Support external U disk data storage; single point, continuous, timing three storage methods are optional
11. Password protection temperature and viscosity correction factor, allowing users to correct themselves
12. Support stepless speed measurement viscosity, easy to select test conditions
13. Automatic conversion of dynamic viscosity and kinematic viscosity
14. Any exchange of various viscosity units
15. Interchange of a variety of user-friendly operation styles
16. Random comes with powerful operation wizard help
17. The viscosity value shows continuous change
18. There is an alarm sound beyond the measurement range
19. Computer full-scale linear correction
20. AC Power Adapter 100V-240V, good anti-interference
Principle
The intelligent Viscometer measures viscosity based on the resistance of the rotor as it swirls/spins in the liquid, processes the data quickly with an ARM chip processor, and monitors the temperature with the built-in RTD Temperature Probe. It supports stepless speed, and the input speed directly reflects the full scale under each rotor for accurate measurement.
Applications
Glue, latex, solvent adhesives, polymer solutions, petroleum, paints, solvents, cosmetics, milk products, products, fruit juices
Steps
1. Connect the Power Adapter and turn it on
2. Select measurement mode and parameters via Touchscreen
3. Install the appropriate rotor and set the speed
4. Place the sample in the measurement position to start measurement
5. Observe viscosity changes and alarm prompts
6. Save data using a USB stick or network interface
Notice
• Power frequency in 100V-240V range
• Check whether the rotor is firmly installed before use
• Avoid operating beyond the measurement range to prevent damage to the instrument
Periodically calibrate temperature and viscosity correction factors to ensure accuracy
• Choose the appropriate storage method when storing data (single point, continuous or timed)
• Pay attention to anti-static and anti-interference environment settings
