Overview
BGL series blast drying oven has the characteristics of novel shape, professional technology, accurate temperature control, stable performance, easy maintenance and convenient operation. It is suitable for drying, baking, melting wax and heat treatment in laboratories of industrial and mining enterprises, scientific research institutes and other units.
Features
1. Novel vertical design. Cold rolled steel plate is used to form the shell of the box. The surface is treated by electrostatic spraying process. The shape is beautiful and generous, and the anti-corrosion is durable.
2, turbine centrifugal fan blades, unique bottom drum and bottom heater reasonable cooperation, with vertical double air duct vertical hot air circulation, so that the indoor temperature distribution more uniform.
3. The studio is made of good mirror stainless steel, the four corners are semi-circular arc transition surface is treated with anti-corrosion process, the Shelf spacing is adjustable, and the side plate of the air duct and the bottom heating hood are quick-release structure, which is easy to clean.
4, PID microcomputer intelligent temperature control instrument, with timing, over-temperature alarm, accurate temperature control, easy reading.
5. Adopt a low-noise blower.
6. The fan has a speed regulation function, divided into three gears: 1, 2, and 3. The gears are adjusted according to the user's requirements for heating items. It is recommended to use high-speed gears to improve uniformity.
7. The box door with a new structure has good thermal insulation effect, and the middle is equipped with a double-decked tempered Glass large viewing window. It is equipped with a lock-type elastic adjustment door lock and a high-temperature silicone sealing strip to ensure good sealing and prevent heat loss.
Principle
Through the reasonable cooperation between the bottom drum and the bottom heater, with the vertical double air duct vertical hot air circulation, the temperature distribution in the working room is uniform. The PID microcomputer intelligent temperature controller realizes accurate temperature control, and the fan can adjust the speed to adjust the intensity of hot air circulation.
Applications
Laboratory of industrial and mining enterprises and scientific research institutes
Steps
1. Adjust the fan gear according to the requirements of the heating item. It is recommended to use a high-speed gear.
2. Set the timing and temperature parameters of the PID microcomputer intelligent temperature controller.
3. Start the equipment for drying, baking, wax melting or heat treatment operations.
Notice
• It is recommended to use a high speed gear to increase Temperature Uniformity.
• Regularly clean the side plate and bottom heating cover of the air duct to keep the equipment hygienic.
• Note that the Ambient Temperature should be within the range of + 5-40 ° C.
