Overview
BGL series blast drying oven has the characteristics of novel shape, professional technology, accurate temperature control, stable performance, easy maintenance and convenient operation. It is suitable for drying, baking, melting wax and heat treatment in laboratories of industrial and mining enterprises, scientific research institutes and other units.
Features
1. Novel vertical design, the shell is formed by good Cold rolled steel plate processing, surface electrostatic spraying process, beautiful and generous, anti-corrosion and durable
2. Turbine centrifugal fan blades, reasonable cooperation between the bottom drum and the bottom heater, vertical double air ducts vertical hot air circulation, so that the temperature distribution is more uniform
3. The studio adopts good mirror stainless steel processing and forming, four corners and a half arc transition surface anti-corrosion treatment, adjustable Shelf spacing, air duct side plate and bottom heating hood quick-release structure, easy to clean
4, PID microcomputer intelligent temperature control instrument, with timing, over-temperature alarm function, accurate temperature control, convenient reading
5. Adopt a low-noise blower
6. The fan has a speed regulation function, divided into three gears: 1, 2, and 3, which can be adjusted according to the requirements of heating items
7. The new structure box door has good thermal insulation effect, double-decked tempered Glass large viewing window in the middle, lock-type elastic adjustment door lock, high temperature silicone sealing strip to ensure good sealing and prevent heat loss
Principle
Through the turbine centrifugal fan blades for base blast, with the bottom heater reasonable cooperation, the formation of vertical double air duct vertical hot air circulation system, so that the indoor temperature distribution more uniform, accurate temperature control.
Applications
Industrial and mining enterprises, scientific research institutes laboratory drying, baking, wax, heat treatment
Steps
1. Turn on the power supply
2. Set the required temperature
3. Adjust the fan gear as needed
4. Set the timing time
5. Start the device and start working
6. Turn off the equipment after the work is completed
Notice
• It is recommended to use a high-speed gear for higher uniformity
• Ambient Temperature should be in the range of + 5-40 ℃
• Maximum total load does not exceed 25kg
• Regularly clean the side plate and bottom heating hood of the air duct
• Make sure the door is well sealed to prevent heat loss
