Overview
BENTING CBGLL-125BE blast drying oven has excellent design, novel shape, professional technology, accurate temperature control, stable performance, easy maintenance and convenient operation. It is suitable for drying, baking, wax, heat treatment and other purposes in laboratories of industrial and mining enterprises, scientific research institutes and other units.
Features
1. Novel vertical design, the shell is made of good steel plate, surface electrostatic spray, beautiful appearance, anti-corrosion and durability.
2. Four corners arc transition, Shelf spacing adjustable, duct side plate and bottom heating hood quick-release structure, easy to clean.
3. Turbine centrifugal fan blade base drum and bottom heating are reasonably coordinated, vertical double air duct vertical hot air circulation, uniform temperature distribution.
4. Speed-regulating fan, which can adjust the air volume to ensure temperature uniformity and does not blow away powdery items.
5. Large-screen LCD multi-group data display, user-friendly navigation operation keys, with timing, over-temperature alarm, parameter memory call reply function.
6. Independent temperature limit alarm system, timely alarm to cut off the output when the main controller fails, double protection experimental safety.
7. Optional 485 interface, which can be connected to a computer to remotely monitor temperature parameters.
8. The box door has good thermal insulation effect, double-decked tempered Glass large viewing window, lock-type elastic adjustment door lock, high temperature silicone sealing strip, good sealing performance, to prevent heat loss.
Principle
Through the turbine centrifugal fan blade, the base drum air and bottom heating are reasonably coordinated, and the vertical double air duct vertical hot air circulation design is adopted to make the temperature distribution in the working room more uniform; the speed regulating fan can adjust the air volume according to the experimental needs to ensure the temperature uniformity.
Applications
Industrial and mining enterprises, scientific research institutes laboratory drying, baking, wax, heat treatment
Steps
1. Connect the power supply and set the required temperature and time parameters.
2. Adjust the fan air volume as required.
3. Start the device and monitor temperature changes.
4. After use, turn off the power supply and perform cleaning and maintenance.
Notice
• Ambient Temperature should be maintained at + 5-40 ° C.
• Maximum total load does not exceed 25kg.
• Avoid use in humid or flammable environments.
• Regularly clean air ducts and heat hoods to maintain performance.
• In case of power outage or crash, the device has a parameter memory function, which can be restored after an incoming call.
• Pay attention to the over-temperature alarm and deal with abnormal situations in time.
