BENTING C101-2AB blast Drying Oven stainless steel studio intelligent temperature control

Name: BENTING C101-2AB blast Drying Oven stainless steel studio intelligent temperature control
Brand: BenTing
SKU: NB028580

Please contact customer service

PID control program to achieve accurate temperature control, Temperature Fluctuation +/- 1.0 ℃, equipped with double-decked tempered Glass observation window for real-time monitoring, single air duct design combined with low noise fan to improve temperature uniformity.

Model

C101-2AB

Get Quote

Category : Drying Oven

Brand : BenTing

SKU : NB028580

Service :The delivery and service By NBCLab.Com

Overview

BENTING C101-2AB blast drying oven is suitable for drying, baking, melting wax, sterilizing and curing in laboratories and R & D institutions of industrial and mining enterprises.

Features

1. The shell is made of good Cold rolled steel plate, the surface is treated by lame plating process, and the studio is made of stainless steel and treated by anti-corrosion process. 2. The intelligent temperature controller uses a PID control program, digital display, and a timing function. 3. The middle of the box door is equipped with a double-decked tempered Glass observation window, which can observe the condition of the heated items in the working room at any time. 4, the door with silicone rubber sealing, sealing effect is good. 5. Blower type is equipped with low noise fan, single air duct design, to ensure good Temperature Uniformity in the studio.

Principle

The air drying oven heats the studio through the heating system, and cooperates with the low-noise fan and single air duct design to achieve hot air circulation, so that the temperature in the working room is evenly distributed. The intelligent temperature controller uses the PID control program to precisely adjust the temperature and digitally display the real-time temperature status.

Applications

Industrial and mining enterprise laboratories, R & D institutions

Temperature Range
RT+10-250℃
Temperature Fluctuation
±1.0℃
Volume
136L
Inner chamber dimensions
550*450*550mm
Liner material
stainless steel
shelf (std.)
2 pieces
Load per shelf
15kg
Power supply
220V/50HZ
input power
2Kw
Operating temperature
20℃
Operating environment humidity
50％RH
dimensions
850*600*725mm
net weight
58kg
Enclosure Material
Cold rolled steel plate
Packaging Dimensions
1010*740*870mm
gross weight
79kg
