Overview
Pottery and porcelain fiber muffle furnace design, suitable for industrial and mining enterprises, R & D institutions and other laboratories for chemical analysis, physical determination and general small steel heat treatment heating.
Features
1. Pottery and porcelain fiber liner, cost-effective equipment
2. Intelligent controller, good temperature control effect; a large number of exports to European countries
3. Digital one-screen display, temperature, time and other parameters
4. The product is durable, and the parameters are presented without reservation
5. Streamlined luxury machine shape, electrostatic spray box
6. The furnace body is made of refractory brick material, and the thermal insulation performance is good
7. LED large-screen LCD display displays various set parameters and measured parameters
8. Microcomputer P.I.D temperature controller with over-temperature deviation protection, timing function, accurate and reliable temperature control
9. Upgraded sound and light alarm environment scanning microcomputer chip, powerful data processing function
10.Over-temperature alarm, regular shutdown, call recovery, parameter encryption, temperature correction and other functions
11. Power-off recovery function. After the external power supply loses power and calls again, it can automatically resume operation according to the original setting program.
12. Comprehensive safety protection design to achieve triple safety protection for personnel, samples, and equipment
Principle
The microcomputer P.I.D temperature controller is used to achieve accurate temperature control, heating the furnace through heating elements, and an intelligent control system is equipped to achieve precise control and protection of temperature, time and other parameters.
Applications
Industrial and mining enterprises, R & D institutions, chemical analysis, physical measurement, heat treatment of small steel parts
Steps
1. Connect the AC220V 50Hz power supply
2. Set the temperature parameters through the LCD liquid crystal display (Temperature range: room temperature + 50~ 1000 ℃)
3. Set Timer Range 1~ 9999 minutes
Step 4 Start the heating program
5. Manual door opening operation
6. The equipment automatically runs according to the set program, with power failure recovery function
Notice
• Ambient Temperature should be kept within 5 ℃~ 40 ℃
• Sensor fault alarm, over-temperature alarm and other safety tips
• Use independent over-lift preventer and over-temperature protector to ensure safety
• Pay attention to the overcurrent trip protection function
• Regularly check the operating status of the equipment
• Use the equipment in strict accordance with the operating specifications
