Overview
The BENTING CSX-12-10 resistance furnace is an all-in-one designed laboratory heating equipment with a maximum temperature of 1000 ° C. It is equipped with a PID microcomputer temperature control system and a precision Sensor to ensure accurate temperature control.
Features
1. Integrated design, lightweight and compact structure
2. Closed aluminum silicate furnace, lightweight insulation brick to ensure full use of heat
3. Parallel side-opening furnace door to keep the hot end away from operation
4. PID Microcomputer Thermostat Combined with Precision Sensor for Accurate Temperature
5. Dedicated function keys to achieve temperature setting
6. Auxiliary menu to achieve over-rise alarm, deviation correction, menu lock
7. Optional exhaust device, conducive to ashing
8. Nickel-chromium-aluminum alloy heating wire is closed and embedded in the aluminum silicate furnace to reduce the corrosion of volatile gas on the heating wire
9. Silicon carbide rod heating, rapid heating, high thermal efficiency
Principle
The resistance furnace generates heat through the nickel-chromium-aluminum alloy heating wire, and uses three-sided heating to heat the furnace. The PID microcomputer temperature control system monitors the temperature in real time through the K-type Thermocouple to achieve accurate temperature control and stage heating.
Applications
Laboratory heating, material handling, sample ashing
Steps
1. Use the touch of four buttons to set the temperature
2. Select fixed-value operation, regular operation or automatic stop mode
3. Set timer 0~ 9999 minutes
Step 4 Start the heating program
5. Monitor the temperature display
Notice
● Pay attention to the over-rise alarm function
● Can use the menu button lock function
● Optional exhaust device is conducive to ashing operation
● Note the power requirements AC380V/12A 50/60Hz
● Equipment gross weight 305kg, need to pay attention to handling safety
