Overview
The LEICI WZB-172 Turbidimeter is a 3.5-inch high definition color LCD screen Portable measuring instrument that supports scattering and scattering-transmission Measurement principle switching, conforms to ISO 7027 and HJ 1075 standards, and is suitable for water quality turbidity detection.
Features
1. Adopt 3.5-inch high definition color LCD screen, clear display
2. Infrared LED Illuminant, ISO 7027 and HJ 1075 compliant
3. Support scattering method and scattering-transmission method Measuring method switching
4. Automatic range switching
5. Support NTU, FNU, EBC Measurement unit switching
6. Support Standard measurement and Average Measurement mode
7. Support zero point correction and turbidity calibrating
8. Data storage, access, deletion, transfer and printing
9. Compliant with GLP for data traceability
10. Large-capacity lithium battery power supply, support connecting PC and mobile power supply charging
11. IP65 Protection Ratings
12. Standard turbidity bottle, Portable protective case and long-lasting turbidity calibrating set
Principle
Measurement principles of scattering and scattering-transmitted light were used to calculate the turbidity value by illuminating the sample with 860nm LED Illuminant and detecting the intensity of scattered light.
Applications
Water quality testing, environment monitoring, industrial process control
Standards
ISO 7027、HJ 1075
Steps
1. Power on and select Measuring method
2. Perform zero correction
3. Perform turbidity calibrating as required
4. Put in the sample for measurement
5. Viewing, storing, or transferring data
Notice
• Operating Environment Temperature should be within 5~ 40 ℃
• relative humidity not more than 85%
• Charge with standard Power Adapter
Periodically calibrated to ensure measurement accuracy
• Pay attention to the battery level prompt and charge it in time.
