LEICI E-301-CF pH Triple Composite ElectRode Waterproof BNC Triple in One Conventional Sample

Name: LEICI E-301-CF pH Triple Composite ElectRode Waterproof BNC Triple in One Conventional Sample
Brand: LeiCi
SKU: NB030587
Price: 123.0 USD
Availability: InStock

$ 123.00Ex works

Using three-in-one composite structure, equipped with waterproof BNC interface, Measurement range covers 0-14pH, Operating temperature 5-60 ℃, suitable for routine sample testing.

Model

E-301-CF

Get Quote

Category : pH Meter

Brand : LeiCi

SKU : NB030587

Service :The delivery and service By NBCLab.Com

Overview

LEICI E-301-CF pH Triple Composite Electrode is a 3-in-1 conventional sample pH Electrode with a Measurement range of 0-14pH and a Temperature range of 5-60 ° C with waterproof plug-ins.

Features

1. 3-in-1 Composite Design, Integrated Indicator Electrode and Reference Electrode 2. Contains waterproof plug-in to improve Reliability 3. Adopt waterproof BNC connector (Q9 type & Q6 type) 4. Suitable for routine sample pH measurement

Principle

The pH Triple Composite Electrode senses the concentration of hydrogen ions in the sample through the built-in Glass electrode, creating a potential difference, and the reference Electrode provides a stable reference potential for the measurement of the pH value of the solution. The three-in-one design simplifies operation and improves measurement efficiency.

Applications

Conventional sample pH measurement

Steps

1. Connect Electrode to pH Meter to ensure waterproof plug sealing 2. Electrode calibrated using standard buffer solution 3. Immerse the Electrode in the sample to be tested and avoid touching the bottom of the container 4. Record the ph value after waiting for the reading to stabilize 5. Clean Electrodes After Use and Store Properly

Notice

• Avoid Electrode Use Beyond 5-60 ° C • Make sure the waterproof plug-in is intact to prevent moisture from entering Periodically calibrated to ensure measurement accuracy • Use deionized water when cleaning to avoid damage to the sensitive film • Keep Electrode Head Moist During Storage

Technical parameters
0-14pH、5-60℃
Electrode plug
Waterproof BNC (Q9 & Q6)
