Overview
The NIRUN NTV-P2LV Intelligent Viscometer is an advanced viscosity measurement device with a 7-inch wide Touchscreen, providing rich display information and convenient operation experience. It supports a variety of Viscosity units and Measurement modes for a wide range of fluid viscosity detection needs.
Features
1.7 inch wide Touchscreen, easy to operate, rich display information
2. Optional DV data collection and program control software can measure rheological characteristics, and the screen can directly display rheological Linear dispersion
3. Display shear rate and shear stress index
4. Anti-static shell, metal lifting rod design
5. Built-in RTD temperature sensor
6. ARM chip processor, faster data processing speed
7. Durable new small shaft design
8. Powerful human-machine interaction interface
9. Gigabit network port data communication transmission, fast and reliable data transmission
10. Support external U disk Data storage; single point, continuous, timing three storage methods optional
11. Password-protected temperature and viscosity correction coefficients, allowing users to correct temperature and viscosity correction coefficients by themselves with reliable and accurate data
12. Support stepless speed measurement viscosity, input any Rotation speed, directly reflect the full scale under each rotor, convenient for users to select test conditions
13. Automatic conversion of dynamic viscosity and kinematic viscosity
14. Viscosity unit interchangeability
15. Interchange of a variety of user-friendly operation styles
16. Random comes with powerful operation wizard help
17. Viscosity values show continuous change
18. Measurement range beyond the alarm sound prompt
19. Computer full-scale linear correction
20. AC Power Adapter 100V-240V, good anti-interference
Principle
The intelligent Viscometer calculates the viscosity value by swirling/spinning the rotor in the fluid and measuring the resistance of the fluid to the rotor. The built-in ARM chip processes data quickly, and the RTD temperature sensor monitors the temperature in real time. Combined with stepless speed change and multiple unit conversion functions, it ensures accurate and reliable viscosity measurement.
Applications
Glue, emulsion, solvent adhesive, polymer solution, petroleum, paints, solvents, cosmetics, milk products, products, juice
Steps
1. Connect the Power Adapter and turn it on
2. Choose the right rotor and Rotation speed
3. Measuring location of samples
4. Measurement parameters set by Touchscreen
5. Start the measurement and observe the change of viscosity value
6. Save data or export results as needed
Notice
• Power supply voltage within 100V-240V range before use
• Avoid operating beyond the Measurement range to prevent alarm prompts
Periodically calibrate equipment to ensure accuracy
• Choose single point, continuous or timed mode when storing data
• Password protection is required when correcting temperature and viscosity coefficient
