Overview
The NIRUN NTV-P2RV Intelligent Viscometer is a precision measuring instrument with a 7-inch wide Touchscreen, providing rich display information and convenient operation experience. It supports a variety of Viscosity units and Measurement modes for accurate measurement of various fluid viscosities.
Features
1.7 inch wide Touchscreen, easy to operate, rich display information
2. Optional DV data collection and program control software can measure rheological characteristics, and the screen directly displays rheological Linear dispersion
3. Display shear rate and shear stress index
4. Anti-static shell, metal lifting rod design
5. Built-in RTD temperature sensor
6. ARM chip processor, faster data processing speed
7. Durable new small shaft design
8. Powerful human-machine interaction interface
9. Gigabit network port data communication transmission, fast and reliable data transmission
10. Support external U disk Data storage; single point, continuous, timing three storage methods optional
11. Password-protected temperature and viscosity correction factor, allowing users to correct themselves
12. Support stepless speed measurement viscosity, easy to select test conditions
13. Automatic conversion of dynamic viscosity and kinematic viscosity
14. Viscosity unit interchangeability
15. Interchange of a variety of user-friendly operation styles
16. Random comes with powerful operation wizard help
17. Viscosity values show continuous change
18. Measurement range beyond the alarm sound prompt
19. Computer full-scale linear correction
20. AC Power Adapter 100V-240V, good anti-interference
Principle
Intelligent Viscometer calculates viscosity by swirling/spinning the rotor in the fluid and measuring the resistance of the fluid to the rotor. Built-in ARM chip to process data quickly, RTD temperature sensor monitors the temperature in real time to ensure Measurement accuracy. Support stepless speed change and multiple unit conversions for automated viscosity analysis.
Applications
Glue, emulsion, solvent adhesive, polymer solution, petroleum, paints, solvents, cosmetics, milk products, products, juice
Steps
1. Connect the Power Adapter and turn it on
2. Choose the right rotor and Rotation speed
3. Immerse the rotor in the sample
4. Measurement parameters set by Touchscreen
5. Start measurement and observe the change of viscosity value
6. Data can be saved via USB flash drive or network
7. Clean the rotor and shut down after use
Notice
• Power supply voltage in 100V-240V range
• Rotor and temperature parameters calibrated before measurement
• Avoid use beyond Measurement range to prevent alarm
• Regularly clean the rotor and housing to maintain anti-static performance
• Keep passwords safe when using password protection
Operate in a stable environment to reduce interference
