Overview
NIRUN NTV-P2HB Intelligent Viscometer is a precision measuring instrument with 7 inch wide Touchscreen operation, with rich display information and user-friendly Operating interface. It supports a variety of Viscosity units and Measurement modes, suitable for accurate measurement of viscosity of various fluids such as glue, emulsion, solvent adhesive, etc.
Features
1.7 inch wide Touchscreen, easy to operate, rich display information
2. Optional DV data collection and program control software can measure rheological characteristics, and the screen directly displays rheological Linear dispersion
3. Display shear rate and shear stress index
4. Anti-static shell, metal lifting rod design
5. Built-in RTD temperature sensor
6. ARM chip processor, processing data faster
7. Durable new small shaft design
8. Powerful human-machine interaction interface
9. Gigabit network port data communication transmission, fast and reliable data transmission
10. Support external U disk Data storage; single point, continuous, timing three storage methods optional
11. Password-protected temperature and viscosity correction factor, allowing users to correct themselves
12. Support stepless speed measurement viscosity, input Rotation speed directly reflects the full scale of each rotor
13. Automatic conversion of dynamic viscosity and kinematic viscosity
14. Viscosity unit interchangeability
15. Interchange of a variety of user-friendly operation styles
16. Random comes with powerful operation wizard help
17. Viscosity values show continuous change
18. Measurement range beyond the alarm sound prompt
19. Computer full-scale linear correction
20. AC Power Adapter 100V-240V, good anti-interference
Principle
The intelligent Viscometer calculates the viscosity value by swirling/spinning the rotor in the fluid and measuring the resistance of the fluid to the rotor. The built-in ARM chip processes data quickly, and the RTD temperature sensor monitors the temperature in real time, and displays indicators such as shear rate and shear stress through the Touchscreen to achieve accurate viscosity measurement.
Applications
Glue, emulsion, solvent adhesive, polymer solution, petroleum, paints, solvents, cosmetics, milk products, products, juice
Steps
1. Connect the Power Adapter and turn it on
2. Select the appropriate rotor and install it
3. Measurement parameters (such as Rotation speed, unit) set by Touchscreen
4. Measuring location of samples
5. Start the measurement and observe the viscosity value displayed on the screen
6. Save the data to the U disk or transfer it through the network port as needed
7. Clean the rotor after measurement
Notice
• Power supply voltage in 100V-240V range
• Check whether the rotor is firmly installed before measurement
• Avoid operating beyond the Measurement range to prevent alarm prompts
• Regularly calibrate with standard fluid to maintain accuracy
• Protect Touchscreen and Precision Parts When Cleaning
• Choose single point, continuous or timed mode when storing data
• Correction of temperature and viscosity coefficients requires a password and is based on reliable data
