Overview
HUIDA HD-6006-A Breaking strength tester is a special equipment for testing the anti-Breaking strength of corrugated boxes. It is suitable for factories such as electronics, electrical appliances, wires, Hardware, Bicycle, handbags, food, footwear, furniture, etc. The equipment adopts pressure converter induction mode, digital indication, capacity is 0~ 100kg/cm ², clip ring diameter is 0006 31.50mm, Dimension 430 * 530 * 520mm, and can automatically retain the maximum Breaking strength value and print test data.
Features
1. Adopt pressure converter induction method to ensure Test accuracy.
2. Digital indication for easy reading of data.
3. Automatically retain the maximum Breaking strength value to improve test efficiency.
4. Can print test values, averages, times, dates, and other data.
5. Clamp ring diameter is 31.50mm, suitable for standard testing requirements.
Principle
The testing machine transmits pressure by signal, and automatically detects and retains the maximum Breaking strength value when the sample breaks. The pressure converter is used to convert the pressure into an electrical signal, and the result is displayed by a digital indicator, and the print data can be output.
Applications
Electronics, Electrical Appliances, Wire, Hardware, Bicycle, Handbag, Food, Shoe, Furniture and other factories, Corrugated Encasement, Synthetic Leather, Cloth
Standards
JIS-P8112、L1018、ASTM-D2210、TAPPI-T403
Steps
1. Prepare the sample and place it in the clamping ring.
2. Start the device for testing.
3. When the sample breaks, the equipment automatically retains the maximum Breaking strength value.
4. Print test values, averages, times, dates, and other data.
Notice
• Ensure that the sample is properly placed in the clamping ring.
• Test accuracy by calibrating equipment regularly.
• Avoid overloading and prevent equipment damage.
• Pay attention to safety during operation to prevent damage caused by rupture of the sample.
