Overview
YONGLIDA QXP0-100S is an ISO Grindometer (double-channel), part of the QXP double-channel Fineness Gauge series. This model has a two-groove design, the measurement fineness range is 0~ 100 μm, and the Graduation is 10 μm. It is suitable for the standard test of "Coating Fineness Determination Method".
Features
1. Double groove design to improve measurement efficiency
2. The range covers 0~ 100μm to meet the measurement requirements of different fineness
3. Made of Cr12 molybdenum vanadium, wear-resistant and durable
4. Graduation accuracy to 10 μm, Measurement accuracy is high
5. Compliant with ISO standards, suitable for professional Coating Fineness Determination
Principle
The ISO Grindometer determines fineness by placing the sample in the groove and observing the particle distribution after scraping it flat with a drawdown blade. The double-channel design allows for two simultaneous measurements, improving test efficiency and accuracy.
Applications
Coating fineness determination, Coating quality control, Coating R & D experiment
Standards
"Coating Fineness Determination Method"
Steps
1. Place the sample in the Fineness Gauge
2. Use the drawdown blade to evenly scrape the sample surface
3. Observe the particle distribution and read the fineness value
4. Record measurement results
Notice
• Fineness Gauge drying before use
• Uniform force should be maintained when scraping
• Avoid collision between the scraper and hard objects to prevent damage
• Timely cleaning and maintenance after measurement
• Test according to standard operating methods
