Overview
HORIZON DLS-05 Electronic Tensile Tester is a device for mechanical performance testing of materials, suitable for tensile, disbonding, tearing and other performance tests of Plastic films, composite films and other materials.
Features
1. Operation mode of touch keys, LCD display multiple interfaces in real time
2. Can be pulled off and stopped and peak maintained, with over-current, over-voltage, overload and other protection devices
3. Measurable stretching, heat sealing, disbonding, tearing and other items
4. Can be determined elongation force value, fixed force value to measure elongation, can display force value, displacement Linear dispersion
5. Single point speed regulation or stepless speed regulation (1-500mm/min)
60,000 joint adopts cross pin structure, with swing angle limit function, to ensure the test concentricity
7. Control mode closed loop, high control accuracy
Principle
The device applies tensile force to the sample through the motor drive fixture, uses the closed-loop Control system to precisely control the tensile speed and displacement, real-time measurement of force value and deformation, and displays test data and Linear dispersion through the liquid crystal display.
Applications
Plastic film, composite film tensile strength, fracture elongation, Modulus of Elasticity measurement, disbonding, tearing, heat sealing strength and other performance tests
Standards
GB/T13022、GB/T8808、GB 1040、GB/T4850、GB/T 16578、QB/T 2358、QB/T 1130
Steps
1. Connect the power supply and turn it on.
2. Select test methods and parameters
3. Install the specimen in the fixture
4. Start the test, and the device automatically stretches
5. View results and Linear dispersion after the test is complete
6. Use the microprinter to output data
Notice
• Power supply voltage 220V +/- 10%
• Check whether the fixture is firmly installed before the test
• Avoid overloading equipment
• Periodically calibrated force measurement system
• Keep the equipment clean to avoid dust affecting the accuracy
