Overview
HORIZON DLS-05 Electronic Tensile Tester is a professional equipment for mechanical performance testing of Plastic films, composite films and other materials. The equipment can measure tensile strength, elongation at break, Modulus of Elasticity, and supports disbonding, tearing, heat sealing strength and other performance tests.
Features
1. Operation mode with touch keys, LCD display multiple interfaces in real time
2. With pull-off shutdown, peak hold function, equipped with overcurrent, overvoltage, overload protection device
3. Support stretching, heat sealing, disbonding, tearing and other test items
4. Can realize fixed elongation force value, fixed force value to measure elongation, and display force value-displacement Linear dispersion
5. Support single point speed regulation and stepless speed regulation, speed range 1-500mm/min
60,000 joint adopts cross pin structure, with swing angle limit function, to ensure the test concentricity
7. Control mode closed loop, high control accuracy
Principle
Sensor measurement of the force and displacement of the specimen during the tensile process is used to precisely control the Test speed with a closed-loop Control system. The universal joint structure ensures that the specimen is clamped concentrically, eliminates the influence of irregular specimens on the measurement, and displays the test data and Linear dispersion in real time.
Applications
Plastic film, composite film tensile strength, fracture elongation, Modulus of Elasticity measurement, disbonding, tearing, heat sealing strength and other performance tests
Standards
GB/T13022、GB/T8808、GB 1040、GB/T4850、GB/T 16578、QB/T 2358、QB/T 1130
Steps
1. Select test methods and parameters
2. Install the specimen and fix it with a fixture
3. Test speed and Miscellaneous parameters
4. Start testing and observe real-time data
5. View results and Linear dispersion after the test is complete
6. Use the micro printer to output the test report
Notice
• Power supply voltage within 220V +/- 10%
• Check whether the fixture is firmly installed before the test
• Avoid exceeding the maximum load of the equipment by 500N
• Regularly calibrate Sensors to ensure Measurement accuracy
• Use appropriate disbonding test plates and standard pressure rollers
• Pay attention to the concentricity of the specimen clamping
• Follow equipment operating specifications and safety requirements
